Tees

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

Tee
Socket x Socket x Socket

801-002CMSRP = 29.28	1/4	50	300	090
801-003CMSRP = 29.28	3/8	25	150	090
801-005CMSRP = 29.28	1/2	25	200	090
801-007CMSRP = 29.79	3/4	15	120	090
801-010CMSRP = 36.52	1	25	0	090
801-012CMSRP = 77.02	1-1/4	10	0	090
801-015CMSRP = 88.23	1-1/2	10	0	090
801-020CMSRP = 98.21	2	10	0	090
801-025CMSRP = 249.98	2-1/2	10	0	090
801-030CMSRP = 249.98	3	5	0	090
801-040CMSRP = 332.69	4	5	0	090
801-050CMSRP = 822.51	5	5	0	090
801-050CFMSRP = 1784.22	5	1	4	097
801-060CMSRP = 865.82	6	2	0	090
801-080CMSRP = 2480.14	8	2	0	090
801-080CFMSRP = 2196.41	8	1	0	097
801-100CMSRP = 4906.45	10	1	0	091
801-100CFMSRP = 3648.49	10	1	0	097
801-120CMSRP = 7582.86	12	1	0	091
801-120CFMSRP = 4979.41	12	1	0	097
801-140CMSRP = 11274.36	14	1	0	095
801-140CFMSRP = 13008.84	14	1	0	097
801-160CFMSRP = 18584.01	16	1	0	097
801-180CFMSRP = 21784.29	18	1	0	097
801-200CFMSRP = 32962.32	20	1	0	097
801-240CFMSRP = 46266.49	24	1	0	097

Tee - Reducing
Socket x Socket x Socket

801-101CMSRP = 65.29	3/4X1/2	15	120	090
801-130CMSRP = 75.29	1X1/2	15	0	090
801-131CMSRP = 75.29	1X3/4	15	0	090
801-157CMSRP = 143.09	1-1/4X1X3/4	12	0	090
801-158CMSRP = 93.37	1-1/4X1X1	15	0	090
801-159CMSRP = 93.37	1-1/4X1X1-1/4	15	0	090
801-166C1MSRP = 172.64	1-1/4X1/2	10	0	090
801-167CMSRP = 147.34	1-1/4X3/4	12	0	090
801-168CMSRP = 147.34	1-1/4X1	15	0	090
801-202CMSRP = 147.34	1-1/2X1-1/4X1	10	0	090
801-209CMSRP = 153.88	1-1/2X1/2	10	0	090
801-210CMSRP = 153.88	1-1/2X3/4	15	0	090
801-211CMSRP = 153.88	1-1/2X1	10	0	090
801-212CMSRP = 153.88	1-1/2X1-1/4	10	0	090
801-247CMSRP = 183.31	2X1/2	10	0	090
801-248CMSRP = 183.31	2X3/4	10	0	090
801-249CMSRP = 183.31	2X1	10	0	090

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

Tee - Reducing (continued)
Socket x Socket x Socket

801-250CMSRP = 183.31	2X1-1/4	10	0	090
801-251CMSRP = 183.31	2X1-1/2	10	0	090
801-254C1MSRP = 710.24	2X2X4	4	0	090
801-287CMSRP = 210.51	2-1/2X1/2	10	0	090
801-288CMSRP = 210.51	2-1/2X3/4	10	0	090
801-289CMSRP = 210.51	2-1/2X1	10	0	090
801-290CMSRP = 210.51	2-1/2X1-1/4	10	0	090
801-291CMSRP = 210.51	2-1/2X1-1/2	10	0	090
801-292CMSRP = 217.91	2-1/2X2	10	0	090
801-333C1MSRP = 463.33	3X1/2	5	0	090
801-334C1MSRP = 463.33	3X3/4	6	0	090
801-335CMSRP = 374.00	3X3X1	5	0	090
801-336C1MSRP = 448.60	3X1-1/4	5	0	090
801-337CMSRP = 374.00	3X3X1-1/2	5	0	090
801-338CMSRP = 374.00	3X2	5	0	090
801-339CMSRP = 374.00	3X2-1/2	6	0	090
801-415C1MSRP = 568.80	4X1/2	5	0	090
801-416C1MSRP = 568.80	4X3/4	5	0	090
801-417CMSRP = 568.80	4X1	5	0	090
801-418C1MSRP = 568.80	4X1-1/4	5	0	090
801-419CMSRP = 568.80	4X1-1/2	5	0	090
801-420CMSRP = 472.72	4X2	5	0	090
801-421C1MSRP = 636.08	4X2-1/2	5	0	090
801-422CMSRP = 472.72	4X3	5	0	090
801-426C1MSRP = 1638.67	4X6	4	0	090
801-484C1MSRP = 1223.25	5X1-1/2	4	0	090
801-486C1MSRP = 1373.98	5X2	4	0	090
801-486CFMSRP = 1103.81	5X2	1	4	097
801-487CFMSRP = 730.88	5X2-1/2	1	4	097
801-488C1MSRP = 1365.48	5X3	4	0	090
801-490C1MSRP = 1211.44	5X4	4	0	090
801-490CFMSRP = 935.01	5X4	1	4	097
801-523C1MSRP = 1625.96	6X1/2	4	0	090
801-524C1MSRP = 1625.96	6X3/4	5	0	090
801-525CMSRP = 1625.96	6X1	6	0	090
801-525CFMSRP = 739.43	6X1	1	3	097
801-526C1MSRP = 1625.96	6X1-1/4	4	0	090
801-526CFMSRP = 900.69	6X1-1/4	1	3	097
801-527C1MSRP = 1625.96	6X1-1/2	4	0	090
801-527CFMSRP = 842.74	6X1-1/2	1	4	097
801-528CMSRP = 1510.71	6X2	6	0	090
801-528CFMSRP = 883.23	6X2	1	4	097
801-529C1MSRP = 1667.79	6X2-1/2	4	0	090
801-529CFMSRP = 921.48	6X2-1/2	1	3	097
801-530C1MSRP = 1510.71	6X3	5	0	090
801-530CFMSRP = 965.88	6X3	1	3	097
801-532CMSRP = 1335.06	6X4	5	0	090
801-575C1MSRP = 2967.45	8X1	2	0	090
801-575CFMSRP = 1036.98	8X1	1	3	097
801-576CFMSRP = 1053.44	8X1-1/4	1	0	097
801-577CFMSRP = 1061.26	8X1-1/2	1	0	097
801-578C1MSRP = 2822.49	8X2	2	0	090
801-578CFMSRP = 1180.63	8X2	1	2	097
801-579CFMSRP = 1283.12	8X2-1/2	1	2	097

Page 5

Suitable for Oil-Free air handling to 25 psi, not for distribution of compressed air or gas

Spears^® Manufacturing Company

See Spears^® On-line Catalog @ www.spearsmfg.com for Pricing

Schedule 80 CPVC Product
CPVC Schedule 80 Fittings

Print this Book

Tees

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

Tee - Reducing (continued)
Socket x Socket x Socket

801-580C1MSRP = 2822.49	8X3	2	0	090
801-580CFMSRP = 1447.93	8X3	1	2	097
801-582C1MSRP = 2822.49	8X4	2	0	090
801-582CFMSRP = 1557.93	8X4	1	2	097
801-585CMSRP = 2450.80	8X6	2	0	090
801-618CFMSRP = 1616.11	10X1	1	0	097
801-619CFMSRP = 1639.31	10X1-1/4	1	0	097
801-620CFMSRP = 1714.87	10X1-1/2	1	0	097
801-621C1MSRP = 4940.84	10X2	1	0	091
801-621CFMSRP = 1629.62	10X2	1	0	097
801-622CFMSRP = 2021.13	10X2-1/2	1	0	097
801-623C1MSRP = 4688.78	10X3	1	0	091
801-623CFMSRP = 2196.03	10X3	1	0	097
801-624C1MSRP = 4688.78	10X4	1	0	091
801-624CFMSRP = 2321.27	10X4	1	0	097
801-626CMSRP = 4317.76	10X6	1	0	091
801-626CFMSRP = 2544.42	10X6	1	0	097
801-628C1MSRP = 7063.76	10X8	1	0	091
801-628CFMSRP = 2951.31	10X8	1	0	097
801-661CFMSRP = 2765.58	12X2	1	0	097
801-662CFMSRP = 2900.18	12X2-1/2	1	0	097
801-663CFMSRP = 3050.25	12X3	1	0	097
801-664C1MSRP = 8505.14	12X4	1	0	091
801-664CFMSRP = 3176.32	12X4	1	0	097
801-666C1MSRP = 7966.32	12X6	1	0	091
801-666CFMSRP = 3446.53	12X6	1	0	097
801-668CMSRP = 6746.60	12X8	1	0	091
801-668CFMSRP = 3858.41	12X8	1	0	097
801-670C1MSRP = 10295.46	12X10	1	0	091
801-670CFMSRP = 4453.02	12X10	1	0	097
801-691CFMSRP = 7054.01	14X2	1	0	097
801-692CFMSRP = 7315.62	14X2-1/2	1	0	097
801-693CFMSRP = 8232.64	14X3	1	0	097
801-694CFMSRP = 8532.51	14X4	1	0	097
801-696CFMSRP = 9292.46	14X6	1	0	097
801-698C1MSRP = 8280.01	14X8	1	0	095
801-698CFMSRP = 10025.40	14X8	1	0	097
801-700C1MSRP = 8834.18	14X10	1	0	095
801-700CFMSRP = 10965.81	14X10	1	0	097
801-702CMSRP = 9907.49	14X12	1	0	095
801-702CFMSRP = 12055.54	14X12	1	0	097
801-751CFMSRP = 8100.38	16X2	1	0	097
801-752CFMSRP = 8216.33	16X2-1/2	1	0	097
801-753CFMSRP = 8443.44	16X3	1	0	097
801-754CFMSRP = 8757.12	16X4	1	0	097
801-756CFMSRP = 11404.41	16X6	1	0	097
801-758CFMSRP = 12748.44	16X8	1	0	097
801-760CFMSRP = 13799.22	16X10	1	0	097
801-762CFMSRP = 15434.32	16X12	1	0	097
801-764CFMSRP = 17147.66	16X14	1	0	097
801-781CFMSRP = 11011.77	18X2	1	0	097

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

Tee - Reducing (continued)
Socket x Socket x Socket

801-783CFMSRP = 11407.08	18X3	1	097
801-784CFMSRP = 11000.08	18X4	1	097
801-786CFMSRP = 14884.67	18X6	1	097
801-788CFMSRP = 15982.40	18X8	1	097
801-790CFMSRP = 17177.27	18X10	1	097
801-792CFMSRP = 18368.32	18X12	1	097
801-794CFMSRP = 19384.83	18X14	1	097
801-796CFMSRP = 20466.84	18X16	1	097
801-814CFMSRP = 22647.38	20X4	1	097
801-816CFMSRP = 26949.85	20X6	1	097
801-818CFMSRP = 27825.19	20X8	1	097
801-820CFMSRP = 30245.77	20X10	1	097
801-822CFMSRP = 31713.85	20X12	1	097
801-824CFMSRP = 35332.20	20X14	1	097
801-826CFMSRP = 38167.12	20X16	1	097
801-828CFMSRP = 40548.33	20X18	1	097
801-904CFMSRP = 28066.59	24X4	1	097
801-906CFMSRP = 30270.00	24X6	1	097
801-908CFMSRP = 30991.78	24X8	1	097
801-910CFMSRP = 32664.29	24X10	1	097
801-912CFMSRP = 34333.02	24X12	1	097
801-914CFMSRP = 37309.68	24X14	1	097
801-916CFMSRP = 43816.80	24X16	1	097
801-918CFMSRP = 48710.12	24X18	1	097
801-920CFMSRP = 54098.71	24X20	1	097

¹ Sized with Bushing

Tee
Socket x Socket x Fipt

802-002CMSRP = 74.32	1/4	25	150	090
802-005CMSRP = 74.32	1/2	20	120	090
802-007CMSRP = 99.13	3/4	20	160	090
802-010CMSRP = 123.85	1	15	0	090
802-012CMSRP = 145.59	1-1/4	15	0	090
802-015CMSRP = 145.59	1-1/2	10	0	090
802-020CMSRP = 182.84	2	10	0	090
802-025CMSRP = 903.46	2-1/2	5	0	090
802-030CMSRP = 217.93	3	5	0	090
802-040CMSRP = 409.44	4	5	0	090
802-060CFMSRP = 837.92	6	1	2	097
802-080CFMSRP = 1688.87	8	1	2	097

Tee - Reducing
Socket x Socket x Fipt

802-101CMSRP = 46.07	3/4X1/2	15	60	090
802-130CMSRP = 92.48	1X1/2	50	0	090
802-131CMSRP = 92.48	1X3/4	15	0	090
802-166CMSRP = 159.38	1-1/4X1/2	25	0	090
802-167C1MSRP = 159.38	1-1/4X3/4	15	0	090

Made in the U.S.A.

Suitable for Oil-Free air handling to 25 psi, not for distribution of compressed air or gas

See Spears^® On-line Catalog @ www.spearsmfg.com for Pricing

Page 6

Schedule 80 CPVC Product
CPVC Schedule 80 Fittings

Print this Book

Tees

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

Tee - Reducing (continued)
Socket x Socket x Fipt

802-168CMSRP = 159.38	1-1/4X1	10	090
802-209C1MSRP = 235.68	1-1/2X1/2	25	090
802-210C1MSRP = 235.68	1-1/2X3/4	20	090
802-211C1MSRP = 235.68	1-1/2X1	10	090
802-212CMSRP = 235.68	1-1/2X1-1/4	10	090
802-247CMSRP = 295.73	2X1/2	10	090
802-248CMSRP = 295.73	2X3/4	10	090
802-249CMSRP = 295.73	2X1	10	090
802-250C1MSRP = 295.73	2X1-1/4	10	090
802-251C1MSRP = 295.73	2X1-1/2	10	090
802-287CMSRP = 388.48	2-1/2X1/2	10	090
802-288C1MSRP = 388.48	2-1/2X3/4	10	090
802-289C1MSRP = 388.48	2-1/2X1	10	090
802-290C1MSRP = 388.48	2-1/2X1-1/4	10	090
802-291C1MSRP = 388.48	2-1/2X1-1/2	10	090
802-292C1MSRP = 428.82	2-1/2X2	10	090
802-333C1MSRP = 657.20	3X1/2	5	090
802-334C1MSRP = 657.20	3X3/4	5	090
802-335C1MSRP = 657.20	3X1	5	090
802-336C1MSRP = 657.20	3X1-1/4	5	090
802-337C1MSRP = 657.20	3X1-1/2	5	090
802-338C1MSRP = 657.20	3X2	5	090
802-339C1MSRP = 657.20	3X2-1/2	5	090
802-415C1MSRP = 1100.63	4X1/2	5	090
802-416C1MSRP = 1100.63	4X3/4	5	090
802-417C1MSRP = 1100.63	4X1	5	090
802-418C1MSRP = 1100.63	4X1-1/4	5	090
802-419C1MSRP = 1100.63	4X1-1/2	5	090
802-420C1MSRP = 1100.63	4X2	5	090
802-421C1MSRP = 1100.63	4X2-1/2	5	090
802-422C1MSRP = 1100.63	4X3	5	090
802-525C1MSRP = 2145.94	6X1	4	090
802-526C1MSRP = 2145.94	6X1-1/4	4	090
802-527C1MSRP = 2145.94	6X1-1/2	4	090
802-528C1MSRP = 2145.94	6X2	4	090
802-529C1MSRP = 2145.94	6X2-1/2	4	090
802-530C1MSRP = 2145.94	6X3	4	090
802-532C1MSRP = 2463.29	6X4	2	090
802-578C1MSRP = 4080.67	8X2	2	090
802-580C1MSRP = 4080.67	8X3	2	090
802-582C1MSRP = 4080.67	8X4	2	090
802-621C1MSRP = 5985.71	10X2	1	091
802-623C1MSRP = 5985.71	10X3	1	091
802-624C1MSRP = 5985.71	10X4	1	091
802-661C1MSRP = 9931.43	12X2	1	091
802-663C1MSRP = 9931.43	12X3	2	091
802-664C1MSRP = 9931.43	12X4	1	091

¹ Sized with Bushing

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

Tee - Special Reinforced
Socket x Socket x SR Fipt - Stainless Steel Collar

802-005CSRMSRP = 40.67	1/2	50	0	096
802-007CSRMSRP = 59.45	3/4	15	120	096
802-010CSRMSRP = 74.78	1	15	0	096
802-012CSRMSRP = 86.76	1-1/4	15	0	096
802-015CSRMSRP = 86.76	1-1/2	10	0	096
802-020CSRMSRP = 141.82	2	10	0	096
802-030CSRMSRP = 204.23	3	5	0	096
802-040CSRMSRP = 384.76	4	5	0	096

Tee - Special Reinforced Reducing
Socket x Socket x SR Fipt - Stainless Steel Collar

802-072CSRMSRP = 40.67	1/2X1/4	25	200	096
802-098CSRMSRP = 54.34	3/4X1/4	25	100	096
802-101CSRMSRP = 54.34	3/4X1/2	50	0	096
802-128CSR1MSRP = 83.96	1X1/4	15	0	096
802-130CSRMSRP = 33.23	1X1/2	50	0	096
802-131CSRMSRP = 83.96	1X3/4	15	0	096
802-164CSR1MSRP = 111.62	1-1/4X1/4	5	0	096
802-166CSRMSRP = 88.42	1-1/4X1/2	15	0	096
802-168CSRMSRP = 90.25	1-1/4X1	10	0	096
802-207CSR1MSRP = 159.87	1-1/2X1/4	15	0	096
802-211CSRMSRP = 105.98	1-1/2X1	10	0	096
802-212CSRMSRP = 105.98	1-1/2X1-1/4	10	0	096
802-245CSR1MSRP = 183.60	2X1/4	10	0	096
802-247CSRMSRP = 165.29	2X1/2	10	0	096
802-248CSRMSRP = 183.60	2X3/4	10	0	096
802-287CSRMSRP = 126.27	2-1/2X1/2	10	0	096
802-331CSR1MSRP = 350.73	3X1/4	5	0	096
802-413CSR1MSRP = 380.57	4X1/4	5	0	096

¹ Sized with Bushing

Tee - Brass Transition
Socket x Socket x Fipt With Brass Thread Insert

802-005CBRMSRP = 120.67	1/2	20	120	096
802-007CBRMSRP = 241.40	3/4	20	80	096

Not intended to convey or dispense water for human consumption through drinking or cooking

Tee - Brass Transition Reducing
Socket x Socket x Fipt With Brass Thread Insert

802-101CBRMSRP = 149.62

3/4X1/2

096

Not intended to convey or dispense water for human consumption through drinking or cooking

Page 7

Suitable for Oil-Free air handling to 25 psi, not for distribution of compressed air or gas

Spears^® Manufacturing Company

See Spears^® On-line Catalog @ www.spearsmfg.com for Pricing

Schedule 80 CPVC Product
CPVC Schedule 80 Fittings

Print this Book

Tees

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

Tee - Reducing
Socket x Fipt x Socket

803-095CMSRP = 41.22

3/4X1/2X3/4

090

Tee - Special Reinforced Reducing
Socket x SR Fipt - Stainless Steel Collar x Socket
(See also Gauge & Instrument Fittings for additional configurations)

803-095CSRMSRP = 33.48

3/4X1/2X3/4

096

Tee
Fipt x Fipt x Fipt

805-002CMSRP = 65.03	1/4	25	150	090
805-003CMSRP = 65.03	3/8	25	150	090
805-005CMSRP = 65.03	1/2	20	120	090
805-007CMSRP = 93.71	3/4	15	120	090
805-010CMSRP = 100.93	1	15	0	090
805-012CMSRP = 101.48	1-1/4	10	0	090
805-015CMSRP = 106.60	1-1/2	10	0	090
805-020CMSRP = 118.36	2	10	0	090
805-025CMSRP = 582.09	2-1/2	5	0	090
805-030CMSRP = 675.38	3	5	0	090
805-040CMSRP = 1599.98	4	5	0	090
805-060CF1MSRP = 2197.92	6	1	2	090
805-080CF1MSRP = 4346.64	8	1	0	090

¹ Sized with Female Adapter

Tee - Special Reinforced
SR Fipt x SR Fipt x SR Fipt - Stainless Steel Collar

805-002CSRMSRP = 36.42	1/4	25	150	096
805-003CSRMSRP = 36.42	3/8	25	150	096
805-005CSRMSRP = 48.67	1/2	25	150	096
805-007CSRMSRP = 55.77	3/4	25	100	096
805-010CSRMSRP = 83.29	1	15	0	096
805-015CSRMSRP = 88.44	1-1/2	10	0	096
805-020CSRMSRP = 105.31	2	10	0	096

Tee - Street
Spigot x Socket x Socket

844-005CMSRP = 36.62	1/2	25	200	090
844-007CMSRP = 37.26	3/4	15	120	090

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

Tee - Street (continued)
Spigot x Socket x Socket

844-010CMSRP = 45.66	1	15	090
844-012CMSRP = 96.27	1-1/4	10	090
844-015CMSRP = 110.35	1-1/2	10	090
844-020CMSRP = 122.83	2	10	090

90� Ells

90� Ell
Socket x Socket

806-002CMSRP = 31.87	1/4	50	300	090
806-003CMSRP = 31.87	3/8	25	150	090
806-005CMSRP = 12.46	1/2	20	240	090
806-007CMSRP = 15.96	3/4	20	160	090
806-010CMSRP = 25.28	1	25	0	090
806-012CMSRP = 54.75	1-1/4	10	0	090
806-015CMSRP = 61.06	1-1/2	10	0	090
806-020CMSRP = 73.73	2	25	0	090
806-025CMSRP = 169.79	2-1/2	5	0	090
806-030CMSRP = 192.22	3	6	0	090
806-040CMSRP = 346.21	4	5	0	090
806-050CMSRP = 660.88	5	4	0	090
806-050CFMSRP = 870.24	5	1	4	097
806-060CMSRP = 695.69	6	4	0	090
806-080CMSRP = 1702.43	8	2	0	090
806-080CFMSRP = 1234.76	8	1	0	097
806-100CMSRP = 4549.58	10	1	0	091
806-100CFMSRP = 2705.07	10	1	0	097
806-120CMSRP = 6155.57	12	1	0	091
806-120CFMSRP = 4979.96	12	1	0	097
806-140CMSRP = 9612.97	14	1	0	095
806-140CFMSRP = 12388.63	14	1	0	097
806-160CFMSRP = 16912.56	16	1	0	097
806-180CFMSRP = 21185.47	18	1	0	097
806-200CFMSRP = 24353.23	20	1	0	097
806-240CFMSRP = 44084.69	24	1	0	097

90� Ell - Sweep
Socket x Socket

806-005SCMSRP = 24.59	1/2	25	150	090
806-007SCMSRP = 31.67	3/4	25	100	090
806-010SCMSRP = 50.88	1	20	0	090
806-012SCMSRP = 67.24	1-1/4	25	0	090
806-015SCMSRP = 72.24	1-1/2	20	0	090
806-020SCMSRP = 87.51	2	25	0	090

Made in the U.S.A.

Suitable for Oil-Free air handling to 25 psi, not for distribution of compressed air or gas

See Spears^® On-line Catalog @ www.spearsmfg.com for Pricing

Page 8

Schedule 80 CPVC Product
CPVC Schedule 80 Fittings

Print this Book

90� Ells

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

90� Ell - Long Sweep
Socket x Socket

806-005LSCFMSRP = 113.23	1/2	25	0	097
806-007LSCFMSRP = 126.84	3/4	25	0	097
806-010LSCFMSRP = 143.44	1	25	0	097
806-012LSCFMSRP = 150.31	1-1/4	25	0	097
806-015LSCFMSRP = 167.79	1-1/2	25	0	097
806-020LSCFMSRP = 235.39	2	1	10	097
806-025LSCFMSRP = 308.61	2-1/2	1	7	097
806-030LSCFMSRP = 326.57	3	1	5	097
806-040LSCFMSRP = 403.96	4	1	4	097
806-060LSCFMSRP = 595.76	6	1	2	097
806-080LSCFMSRP = 1532.39	8	1	0	097
806-100LSCFMSRP = 2335.03	10	1	0	097

Not Listed for Electrical Conduit Use

90� Ell
Socket x Fipt

807-002CMSRP = 28.23	1/4	25	450	090
807-003CMSRP = 28.23	3/8	25	150	090
807-005CMSRP = 32.96	1/2	20	120	090
807-007CMSRP = 38.71	3/4	20	160	090
807-010CMSRP = 50.67	1	20	0	090
807-012CMSRP = 74.32	1-1/4	10	40	090
807-015CMSRP = 112.57	1-1/2	10	0	090
807-020CMSRP = 144.51	2	10	0	090
807-030CMSRP = 174.17	3	5	0	090
807-040CMSRP = 329.33	4	5	0	090
807-060CMSRP = 829.64	6	3	0	090

90� Ell - Special Reinforced
Socket x SR Fipt - Stainless Steel Collar

807-005CSRMSRP = 19.75	1/2	20	240	096
807-007CSRMSRP = 23.17	3/4	75	0	096
807-010CSRMSRP = 27.93	1	50	0	096
807-012CSRMSRP = 57.69	1-1/4	25	0	096
807-015CSRMSRP = 69.34	1-1/2	10	0	096
807-020CSRMSRP = 86.75	2	10	0	096
807-030CSRMSRP = 126.24	3	5	0	096
807-040CSRMSRP = 233.08	4	5	0	096

90� Ell - Brass Transition
Socket x Fipt With Brass Thread Insert

807-005CBRMSRP = 106.13

1/2

240

096

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

90� Ell - Brass Transition (continued)
Socket x Fipt With Brass Thread Insert

807-007CBRMSRP = 185.29

3/4

160

096

Not intended to convey or dispense water for human consumption through drinking or cooking

90� Ell
Fipt x Fipt

808-002CMSRP = 33.47	1/4	25	450	090
808-003CMSRP = 33.47	3/8	25	150	090
808-005CMSRP = 19.44	1/2	20	120	090
808-007CMSRP = 29.05	3/4	20	120	090
808-010CMSRP = 40.77	1	15	120	090
808-012CMSRP = 78.60	1-1/4	10	40	090
808-015CMSRP = 84.54	1-1/2	10	0	090
808-020CMSRP = 113.31	2	10	0	090
808-025CMSRP = 351.68	2-1/2	5	0	090
808-030CMSRP = 377.14	3	5	0	090
808-040CMSRP = 590.12	4	5	0	090

90� Street Ell
Mipt x Fipt

812-002CMSRP = 47.68	1/4	50	300	090
812-005CMSRP = 34.18	1/2	25	150	090
812-007CMSRP = 41.58	3/4	25	150	090
812-010CMSRP = 59.86	1	50	0	090

90� Ell - Special Reinforced
SR Fipt x SR Fipt - Stainless Steel Collar

808-003CSRMSRP = 11.92	3/8	25	150	096
808-005CSRMSRP = 11.92	1/2	20	120	096
808-007CSRMSRP = 17.47	3/4	20	160	096
808-010CSRMSRP = 22.40	1	50	0	096
808-012CSRMSRP = 43.09	1-1/4	25	0	096
808-015CSRMSRP = 50.75	1-1/2	10	0	096
808-020CSRMSRP = 67.98	2	10	0	096

90� Street Ell
Spigot x Socket

809-005CMSRP = 15.68	1/2	50	200	090
809-007CMSRP = 19.93	3/4	50	0	090
809-010CMSRP = 31.67	1	50	0	090
809-012CMSRP = 68.45	1-1/4	25	0	090
809-015CMSRP = 76.44	1-1/2	10	0	090
809-020CMSRP = 92.23	2	25	0	090
809-025C1MSRP = 186.22	2-1/2	5	0	090
809-030CMSRP = 256.35	3	5	0	090

Page 9

Suitable for Oil-Free air handling to 25 psi, not for distribution of compressed air or gas

Spears^® Manufacturing Company

See Spears^® On-line Catalog @ www.spearsmfg.com for Pricing

Schedule 80 CPVC Product
CPVC Schedule 80 Fittings

Print this Book

90� Ells

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

90� Street Ell (continued)
Spigot x Socket

809-040CMSRP = 461.66	4	4	090
809-060C1MSRP = 927.58	6	1	090
809-080C1MSRP = 2269.94	8	2	090
809-100C1MSRP = 6065.45	10	1	091
809-100CFMSRP = 4280.51	10	1	097
809-120C1MSRP = 8204.24	12	1	091
809-120CFMSRP = 6602.49	12	1	097
809-140C1MSRP = 11146.60	14	1	095
809-140CFMSRP = 10094.52	14	1	097
809-160CFMSRP = 15856.22	16	1	097
809-180CFMSRP = 20170.22	18	1	097
809-200CFMSRP = 47347.29	20	1	097
809-240CFMSRP = 48354.42	24	1	097

1 = Assembled with Molded Components

90� Ell - Reducing
Socket x Fipt

807-101CMSRP = 31.61	3/4X1/2	10	60	090
807-130C1MSRP = 45.17	1X1/2	10	80	090
807-131C1MSRP = 45.17	1X3/4	10	60	090

¹ Sized with Bushing

90� Ell - Special Reinforced Reducing
Socket x SR Fipt - Stainless Steel Collar

807-101CSRMSRP = 25.17	3/4X1/2	50	0	096
807-130CSRMSRP = 27.14	1X1/2	50	0	096

90� Ell - Brass Transition Reducing
Socket x Fipt With Brass Thread Insert

807-101CBRMSRP = 132.73

3/4X1/2

120

096

Not intended to convey or dispense water for human consumption through drinking or cooking

Non 90� Ells

11-1/4� Ell
Socket x Socket

811-005CFMSRP = 67.14	1/2	1	52	097
811-007CFMSRP = 69.19	3/4	20	0	097
811-010CFMSRP = 95.71	1	1	50	097
811-012CFMSRP = 102.08	1-1/4	1	26	097
811-015CMSRP = 76.34	1-1/2	25	0	090
811-020CMSRP = 93.37	2	10	0	090

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

11-1/4� Ell (continued)
Socket x Socket

811-025CFMSRP = 231.16	2-1/2	1	25	097
811-030CMSRP = 245.15	3	10	0	090
811-040CMSRP = 336.55	4	4	0	090
811-050CFMSRP = 429.38	5	1	4	097
811-060CFMSRP = 646.32	6	1	5	097
811-080CFMSRP = 1228.14	8	1	3	097
811-100CFMSRP = 2038.65	10	1	2	097
811-120CFMSRP = 2685.13	12	1	2	097
811-140CFMSRP = 5701.34	14	1	0	097
811-160CFMSRP = 8026.11	16	1	0	097
811-180CFMSRP = 11635.61	18	1	0	097
811-200CFMSRP = 17273.54	20	1	0	097
811-240CFMSRP = 17470.35	24	1	0	097

30� Ell
Socket x Socket

815-005CFMSRP = 67.14	1/2	1	25	097
815-007CFMSRP = 69.19	3/4	1	25	097
815-010CFMSRP = 95.71	1	1	20	097
815-012CFMSRP = 102.08	1-1/4	1	15	097
815-015CFMSRP = 110.07	1-1/2	1	25	097
815-020CFMSRP = 206.93	2	1	25	097
815-025CFMSRP = 231.16	2-1/2	1	18	097
815-030CFMSRP = 257.85	3	1	10	097
815-040CFMSRP = 336.74	4	1	18	097
815-050CFMSRP = 369.73	5	1	4	097
815-060CMSRP = 1036.76	6	5	0	090
815-080CFMSRP = 1228.14	8	1	3	097
815-100CFMSRP = 2038.65	10	1	2	097
815-120CFMSRP = 2685.13	12	1	2	097
815-140CFMSRP = 5701.34	14	1	0	097
815-160CFMSRP = 8026.11	16	1	0	097
815-180CFMSRP = 11635.61	18	1	0	097
815-200CFMSRP = 11713.17	20	1	0	097
815-240CFMSRP = 16454.59	24	1	0	097

22-1/2� Ell
Socket x Socket

816-005CMSRP = 18.00	1/2	20	240	090
816-007CMSRP = 25.91	3/4	20	240	090
816-010CMSRP = 41.29	1	20	160	090
816-010CFMSRP = 95.71	1	1	25	097
816-012CMSRP = 81.03	1-1/4	20	0	090
816-015CMSRP = 83.26	1-1/2	20	0	090
816-015CFMSRP = 110.07	1-1/2	1	25	097
816-020CMSRP = 93.37	2	20	0	090
816-025CMSRP = 234.36	2-1/2	5	0	090
816-025CFMSRP = 231.16	2-1/2	1	18	097
816-030CMSRP = 245.15	3	5	0	090

Made in the U.S.A.

Suitable for Oil-Free air handling to 25 psi, not for distribution of compressed air or gas

See Spears^® On-line Catalog @ www.spearsmfg.com for Pricing

Page 10

Schedule 80 CPVC Product
CPVC Schedule 80 Fittings

Print this Book

Non 90� Ells

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

22-1/2� Ell (continued)
Socket x Socket

816-040CMSRP = 336.55	4	4	0	090
816-050CFMSRP = 429.38	5	1	8	097
816-060CMSRP = 1036.76	6	4	0	090
816-060CFMSRP = 646.32	6	1	8	097
816-080CMSRP = 2156.97	8	4	0	090
816-080CFMSRP = 1228.14	8	1	4	097
816-100CFMSRP = 2038.65	10	1	2	097
816-120CFMSRP = 2685.13	12	1	2	097
816-140CFMSRP = 5701.34	14	1	0	097
816-160CFMSRP = 8026.11	16	1	0	097
816-180CFMSRP = 11635.61	18	1	0	097
816-200CFMSRP = 10985.45	20	1	0	097
816-240CFMSRP = 26562.21	24	1	0	097

45� Ell
Socket x Socket

817-002CMSRP = 47.41	1/4	25	450	090
817-003CMSRP = 47.41	3/8	50	300	090
817-005CMSRP = 15.27	1/2	20	120	090
817-007CMSRP = 22.04	3/4	20	120	090
817-010CMSRP = 35.07	1	15	120	090
817-012CMSRP = 68.93	1-1/4	10	80	090
817-015CMSRP = 70.77	1-1/2	10	0	090
817-020CMSRP = 79.37	2	10	0	090
817-025CMSRP = 162.15	2-1/2	5	0	090
817-030CMSRP = 208.36	3	5	0	090
817-040CMSRP = 286.04	4	5	0	090
817-050CMSRP = 837.16	5	4	0	090
817-050CFMSRP = 369.38	5	1	2	097
817-060CMSRP = 881.23	6	4	0	090
817-080CMSRP = 1833.45	8	2	0	090
817-100CMSRP = 3479.20	10	1	0	091
817-100CFMSRP = 2101.05	10	1	2	097
817-120CMSRP = 6121.07	12	1	0	091
817-120CFMSRP = 2950.02	12	1	0	097
817-140CMSRP = 6824.87	14	1	0	095
817-140CFMSRP = 6171.15	14	1	0	097
817-160CFMSRP = 9007.19	16	1	0	097
817-180CFMSRP = 13938.81	18	1	0	097
817-200CFMSRP = 18439.99	20	1	0	097
817-240CFMSRP = 22239.96	24	1	0	097

15� Ell
Socket x Socket

818-005CFMSRP = 67.14	1/2	1	25	097
818-007CFMSRP = 69.19	3/4	1	23	097
818-010CFMSRP = 95.71	1	1	20	097

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

15� Ell (continued)
Socket x Socket

818-012CFMSRP = 102.08	1-1/4	1	15	097
818-015CFMSRP = 110.07	1-1/2	1	25	097
818-020CFMSRP = 206.93	2	1	25	097
818-025CFMSRP = 231.16	2-1/2	1	18	097
818-030CFMSRP = 257.85	3	1	35	097
818-040CFMSRP = 336.74	4	1	18	097
818-050CFMSRP = 429.38	5	1	4	097
818-060CFMSRP = 646.32	6	1	8	097
818-080CFMSRP = 1228.14	8	1	3	097
818-100CFMSRP = 2038.65	10	1	2	097
818-120CFMSRP = 2685.13	12	1	0	097
818-140CFMSRP = 5701.34	14	1	0	097
818-160CFMSRP = 8026.11	16	1	0	097
818-180CFMSRP = 11635.61	18	1	0	097
818-200CFMSRP = 10702.51	20	1	0	097
818-240CFMSRP = 17923.96	24	1	0	097

45� Ell
Fipt x Fipt

819-002CMSRP = 44.52	1/4	25	450	090
819-003CMSRP = 44.52	3/8	25	150	090
819-005CMSRP = 42.18	1/2	25	150	090
819-007CMSRP = 46.34	3/4	10	60	090
819-010CMSRP = 50.99	1	10	60	090
819-012CMSRP = 87.13	1-1/4	10	80	090
819-015CMSRP = 87.13	1-1/2	10	0	090
819-020CMSRP = 114.99	2	10	0	090
819-025CMSRP = 218.01	2-1/2	5	0	090
819-030CMSRP = 313.99	3	5	0	090
819-040CMSRP = 493.93	4	5	0	090

45� Ell - Special Reinforced
SR Fipt x SR Fipt - Stainless Steel Collar

819-005CSRMSRP = 22.31	1/2	25	150	096
819-007CSRMSRP = 27.26	3/4	25	300	096
819-010CSRMSRP = 33.04	1	10	60	096

60� Ell
Socket x Socket

824-005CFMSRP = 192.55	1/2	1	25	097
824-007CFMSRP = 229.93	3/4	25	0	097
824-010CFMSRP = 217.72	1	1	15	097
824-012CFMSRP = 222.98	1-1/4	1	16	097
824-015CFMSRP = 241.45	1-1/2	1	15	097
824-020CFMSRP = 304.09	2	1	16	097
824-025CFMSRP = 348.04	2-1/2	1	10	097
824-030CFMSRP = 597.13	3	1	4	097

Page 11

Suitable for Oil-Free air handling to 25 psi, not for distribution of compressed air or gas

Spears^® Manufacturing Company

See Spears^® On-line Catalog @ www.spearsmfg.com for Pricing

Schedule 80 CPVC Product
CPVC Schedule 80 Fittings

Print this Book

Non 90� Ells

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

60� Ell (continued)
Socket x Socket

824-040CFMSRP = 716.80	4	1	4	097
824-060CFMSRP = 994.75	6	1	2	097
824-080CFMSRP = 1507.20	8	1	2	097
824-100CFMSRP = 3034.19	10	1	0	097
824-120CFMSRP = 4690.01	12	1	0	097
824-140CFMSRP = 11306.18	14	1	0	097
824-160CFMSRP = 15873.56	16	1	0	097
824-180CFMSRP = 22021.69	18	1	0	097
824-200CFMSRP = 29470.23	20	1	0	097
824-240CFMSRP = 49108.44	24	1	0	097

45� Street Ell
Spigot x Socket

827-005CMSRP = 15.27	1/2	50	400	090
827-007CMSRP = 22.04	3/4	50	0	090
827-010CMSRP = 35.07	1	50	0	090
827-012CMSRP = 68.93	1-1/4	25	0	090
827-015CMSRP = 70.64	1-1/2	25	0	090
827-020CMSRP = 79.37	2	10	0	090
827-025C1MSRP = 175.64	2-1/2	12	0	090
827-030CMSRP = 208.36	3	10	0	090
827-040CMSRP = 286.04	4	5	0	090
827-050CFMSRP = 547.23	5	1	2	097
827-060CMSRP = 1036.76	6	4	0	090
827-080CMSRP = 2156.97	8	2	0	090
827-100C1MSRP = 4093.18	10	1	0	091
827-120C1MSRP = 7201.23	12	1	0	091
827-140CFMSRP = 8822.49	14	1	0	097
827-160CFMSRP = 11285.27	16	1	0	097
827-180CFMSRP = 16466.44	18	1	0	097
827-200CFMSRP = 27613.57	20	1	0	097
827-240CFMSRP = 27560.56	24	1	0	097

1 = Assembled with Molded Components

22-1/2� Street Ell
Spigot x Socket

842-005CMSRP = 20.49	1/2	50	400	090
842-007CMSRP = 31.98	3/4	50	0	090
842-010CMSRP = 49.99	1	50	0	090
842-012CMSRP = 62.64	1-1/4	20	0	090
842-015CMSRP = 90.02	1-1/2	25	0	090
842-020CMSRP = 113.55	2	20	0	090
842-025CMSRP = 208.51	2-1/2	5	0	090
842-030CMSRP = 302.77	3	5	0	090
842-040CMSRP = 388.27	4	4	0	090
842-060CMSRP = 1280.38	6	6	0	090
842-080CMSRP = 2684.40	8	1	2	090

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

22-1/2� Street Ell (continued)
Spigot x Socket

842-100CFMSRP = 2071.29	10	1	2	097
842-120CFMSRP = 2747.20	12	1	2	097

Crosses

Cross
Socket x Socket x Socket x Socket

820-002CMSRP = 124.82	1/4	25	150	090
820-005CMSRP = 124.82	1/2	50	0	090
820-007CMSRP = 131.34	3/4	50	0	090
820-010CMSRP = 145.59	1	50	0	090
820-012CMSRP = 155.77	1-1/4	25	0	090
820-015CMSRP = 169.33	1-1/2	25	0	090
820-020CMSRP = 219.59	2	10	0	090
820-025CMSRP = 292.77	2-1/2	10	0	090
820-030CMSRP = 372.87	3	5	0	090
820-040CMSRP = 666.06	4	3	0	090
820-060CFMSRP = 1750.36	6	1	0	097
820-080CFMSRP = 3329.39	8	1	0	097
820-100CFMSRP = 4952.66	10	1	0	097
820-120CFMSRP = 7036.97	12	1	0	097
820-140CFMSRP = 19016.04	14	1	0	097
820-160CFMSRP = 22666.02	16	1	0	097
820-180CFMSRP = 30473.49	18	1	0	097

Cross - Reducing
Socket x Socket x Socket x Socket

820-101C1MSRP = 162.84	3/4X1/2	50	090
820-130C1MSRP = 193.20	1X1/2	25	090
820-131CMSRP = 193.20	1X3/4	20	090
820-166C1MSRP = 172.81	1-1/4X1/2	25	090
820-167CMSRP = 140.19	1-1/4X3/4	25	090
820-168C1MSRP = 277.43	1-1/4X1	25	090
820-209C1MSRP = 306.56	1-1/2X1/2	20	090
820-210CMSRP = 306.56	1-1/2X3/4	15	090
820-211C1MSRP = 306.56	1-1/2X1	25	090
820-212C1MSRP = 306.56	1-1/2X1-1/4	25	090
820-247C1MSRP = 396.94	2X1/2	10	090
820-248C1MSRP = 396.94	2X3/4	10	090
820-249C1MSRP = 396.94	2X1	10	090
820-250C1MSRP = 396.94	2X1-1/4	10	090
820-251C1MSRP = 396.94	2X1-1/2	10	090
820-289CMSRP = 269.88	2-1/2X1	15	090
820-290C1MSRP = 509.16	2-1/2X1-1/4	10	090
820-291C1MSRP = 509.16	2-1/2X1-1/2	8	090
820-292C1MSRP = 509.16	2-1/2X2	10	090
820-335C1MSRP = 701.08	3X1	4	090
820-336C1MSRP = 701.08	3X1-1/4	4	090
820-337C1MSRP = 701.08	3X1-1/2	4	090

Made in the U.S.A.

Suitable for Oil-Free air handling to 25 psi, not for distribution of compressed air or gas

See Spears^® On-line Catalog @ www.spearsmfg.com for Pricing

Page 12

Schedule 80 CPVC Product
CPVC Schedule 80 Fittings

Print this Book

Crosses

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

Cross - Reducing (continued)
Socket x Socket x Socket x Socket

820-338C1MSRP = 701.08	3X2	4	0	090
820-339C1MSRP = 701.08	3X2-1/2	4	0	090
820-420C1MSRP = 1034.08	4X2	3	0	090
820-422C1MSRP = 1034.08	4X3	3	0	090
820-420CFMSRP = 1016.14	4X2	1	3	097
820-528CFMSRP = 1594.07	6X2	1	3	097
820-530CFMSRP = 1800.87	6X3	1	2	097
820-532CFMSRP = 1844.45	6X4	1	2	097
820-578CFMSRP = 2077.23	8X2	1	2	097
820-580CFMSRP = 2180.20	8X3	1	0	097
820-582CFMSRP = 2041.64	8X4	1	0	097
820-585CFMSRP = 2682.53	8X6	1	0	097
820-621CFMSRP = 2490.77	10X2	1	0	097
820-623CFMSRP = 2678.00	10X3	1	0	097
820-624CFMSRP = 2799.62	10X4	1	0	097
820-626CFMSRP = 3344.54	10X6	1	0	097
820-628CFMSRP = 3872.11	10X8	1	0	097
820-661CFMSRP = 3041.25	12X2	1	0	097
820-663CFMSRP = 3342.12	12X3	1	0	097
820-664CFMSRP = 3528.69	12X4	1	0	097
820-666CFMSRP = 4098.17	12X6	1	0	097
820-668CFMSRP = 4780.41	12X8	1	0	097
820-670CFMSRP = 5689.12	12X10	1	0	097
820-691CFMSRP = 5856.65	14X2	1	0	097
820-693CFMSRP = 6185.57	14X3	1	0	097
820-694CFMSRP = 6460.31	14X4	1	0	097
820-696CFMSRP = 8886.83	14X6	1	0	097
820-698CFMSRP = 10104.86	14X8	1	0	097
820-700CFMSRP = 11251.79	14X10	1	0	097
820-702CFMSRP = 12827.33	14X12	1	0	097
820-751CFMSRP = 8318.00	16X2	1	0	097
820-753CFMSRP = 8667.60	16X3	1	0	097
820-754CFMSRP = 9006.36	16X4	1	0	097
820-756CFMSRP = 11958.46	16X6	1	0	097
820-758CFMSRP = 13217.97	16X8	1	0	097
820-762CFMSRP = 15493.72	16X12	1	0	097
820-764CFMSRP = 20316.03	16X14	1	0	097
820-781CFMSRP = 11141.51	18X2	1	0	097
820-783CFMSRP = 11565.86	18X3	1	0	097
820-784CFMSRP = 13444.13	18X4	1	0	097
820-786CFMSRP = 15391.56	18X6	1	0	097
820-788CFMSRP = 16806.35	18X8	1	0	097
820-790CFMSRP = 18430.40	18X10	1	0	097
820-792CFMSRP = 20012.09	18X12	1	0	097
820-794CFMSRP = 24863.36	18X14	1	0	097
820-796CFMSRP = 27877.03	18X16	1	0	097

¹ Sized with Bushing

Couplings

Part Number

Size

Gasket to Gasket - L1

Std Pk

Mstr
Ctn

Prod
Code

Repair Coupling - Fabricated
Gasket x Gasket

828-020CFMSRP = 267.44	2	6	1	15	097
828-030CFMSRP = 340.66	3	11- 3/4	1	5	097
828-040CFMSRP = 424.45	4	15	1	4	097
828-060CFMSRP = 491.86	6	18-1/4	1	2	097
828-080CFMSRP = 1322.42	8	19	1	2	097
828-100CFMSRP = 1426.66	10	21-1/4	1	0	097
828-120CFMSRP = 1877.17	12	21-3/8	1	0	097
828-140CFMSRP = 5525.29	14	21	1	0	097
828-160CFMSRP = 7822.95	16	22-1/4	1	0	097
828-180CFMSRP = 12655.02	18	22-5/8	1	0	097
828-200CFMSRP = 18627.65	20	23-1/2	1	0	097
828-240CFMSRP = 26994.69	24	23-1/2	1	0	097

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

Coupling
Socket x Socket

829-002CMSRP = 33.94	1/4	25	450	090
829-003CMSRP = 33.94	3/8	25	150	090
829-005CMSRP = 13.17	1/2	25	150	090
829-007CMSRP = 18.45	3/4	15	90	090
829-010CMSRP = 24.85	1	15	90	090
829-012CMSRP = 37.19	1-1/4	10	60	090
829-015CMSRP = 46.80	1-1/2	10	40	090
829-020CMSRP = 54.44	2	20	0	090
829-025CMSRP = 121.09	2-1/2	10	0	090
829-030CMSRP = 131.60	3	5	0	090
829-040CMSRP = 172.44	4	5	0	090
829-050CMSRP = 385.86	5	6	0	090
829-050CFMSRP = 206.00	5	1	10	097
829-060CMSRP = 406.15	6	4	0	090
829-080CMSRP = 1097.67	8	4	0	090
829-100CMSRP = 1380.75	10	1	0	091
829-100CFMSRP = 759.91	10	1	0	097
829-120CMSRP = 1617.18	12	1	0	091
829-120CFMSRP = 1027.77	12	1	0	097
829-140CMSRP = 2057.76	14	1	0	095
829-140CFMSRP = 1712.21	14	1	0	097
829-160CFMSRP = 2626.65	16	1	0	097
829-180CFMSRP = 2988.27	18	1	0	097
829-200CFMSRP = 4254.06	20	1	0	097
829-240CFMSRP = 5168.73	24	1	0	097

Page 13

Suitable for Oil-Free air handling to 25 psi, not for distribution of compressed air or gas

Spears^® Manufacturing Company

See Spears^® On-line Catalog @ www.spearsmfg.com for Pricing

Schedule 80 CPVC Product
CPVC Schedule 80 Fittings

Print this Book

Couplings

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

Coupling - Reducer
Socket x Socket

829-101CMSRP = 34.48	3/4X1/2	50	400	090
829-130CMSRP = 49.23	1X1/2	25	200	090
829-131CMSRP = 49.23	1X3/4	25	200	090
829-166CMSRP = 112.74	1-1/4X1/2	25	0	090
829-167CMSRP = 112.74	1-1/4X3/4	25	0	090
829-168CMSRP = 112.74	1-1/4X1	25	0	090
829-209CMSRP = 111.81	1-1/2X1/2	25	0	090
829-210CMSRP = 111.81	1-1/2X3/4	25	0	090
829-211CMSRP = 111.81	1-1/2X1	25	0	090
829-212CMSRP = 111.81	1-1/2X1-1/4	25	0	090
829-247CMSRP = 147.86	2X1/2	25	0	090
829-248CMSRP = 147.86	2X3/4	10	80	090
829-249CMSRP = 147.86	2X1	25	0	090
829-250CMSRP = 147.86	2X1-1/4	10	0	090
829-251CMSRP = 147.86	2X1-1/2	10	40	090
829-290C1MSRP = 238.74	2-1/2X1-1/4	10	0	090
829-291CMSRP = 168.39	2-1/2X1-1/2	10	0	090
829-292CMSRP = 168.39	2-1/2X2	10	0	090
829-335C1MSRP = 416.44	3X1	8	0	090
829-336C1MSRP = 429.17	3X1-1/4	6	0	090
829-337CMSRP = 429.17	3X1-1/2	8	0	090
829-338CMSRP = 340.21	3X2	10	0	090
829-339CMSRP = 341.66	3X2-1/2	10	0	090
829-339CFMSRP = 324.59	3X2-1/2	1	9	097
829-416C1MSRP = 490.62	4X3/4	4	0	090
829-417C1MSRP = 490.62	4X1	4	0	090
829-419C1MSRP = 490.62	4X1-1/2	4	0	090
829-420CMSRP = 405.83	4X2	6	0	090
829-421CMSRP = 405.83	4X2-1/2	4	0	090
829-422CMSRP = 405.83	4X3	4	0	090
829-488CF1MSRP = 400.42	5X3	1	6	097
829-490CF1MSRP = 252.59	5X4	1	6	097
829-528C1MSRP = 1073.67	6X2	6	0	090
829-529C1MSRP = 1265.34	6X2-1/2	4	0	090
829-530C1MSRP = 1095.62	6X3	12	0	090
829-532CMSRP = 921.89	6X4	4	0	090
829-533CFMSRP = 576.45	6X5	1	5	097
829-579CF1,2MSRP = 2386.64	8X2-1/2	1	4	097
829-580CF1,2MSRP = 976.39	8X3	1	6	097
829-582C1MSRP = 1672.87	8X4	2	0	090
829-582CF1,2MSRP = 865.58	8X4	1	4	097
829-583CF2MSRP = 1014.06	8X5	1	4	097
829-585CMSRP = 1597.35	8X6	2	0	090
829-621CF1,3MSRP = 1808.73	10X2	1	2	097
829-623CF1,3MSRP = 1516.93	10X3	1	2	097
829-624CF3MSRP = 1458.04	10X4	1	2	097
829-625CF3MSRP = 1571.54	10X5	1	2	097
829-626CMSRP = 2484.08	10X6	1	0	091

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

Coupling - Reducer (continued)
Socket x Socket

829-626CF2MSRP = 1122.65	10X6	1	2	097
829-628CMSRP = 2484.08	10X8	1	0	091
829-628CFMSRP = 1471.07	10X8	1	4	097
829-663CF1,4MSRP = 3296.15	12X3	1	2	097
829-664CF4MSRP = 3245.29	12X4	1	2	097
829-665CF4MSRP = 3243.02	12X5	1	0	097
829-666CF3MSRP = 3018.25	12X6	1	0	097
829-668CMSRP = 2706.52	12X8	1	0	091
829-668CF2MSRP = 2309.68	12X8	1	0	097
829-670CFMSRP = 1231.67	12X10	1	2	097
829-694CF4MSRP = 4711.48	14X4	1	0	097
829-696CF3MSRP = 4449.59	14X6	1	0	097
829-698CF2MSRP = 3704.43	14X8	1	0	097
829-700CFMSRP = 3170.65	14X10	1	0	097
829-702CFMSRP = 2773.65	14X12	1	0	097
829-754CF5MSRP = 5804.22	16X4	1	0	097
829-756CF4MSRP = 5973.56	16X6	1	0	097
829-758CF3MSRP = 6827.80	16X8	1	0	097
829-760CF2MSRP = 6540.02	16X10	1	0	097
829-762CFMSRP = 6198.33	16X12	1	0	097
829-764CFMSRP = 5506.95	16X14	1	0	097
829-783CF1,6MSRP = 11960.55	18X3	1	0	097
829-784CF6MSRP = 11866.57	18X4	1	0	097
829-786CF5MSRP = 11778.00	18X6	1	0	097
829-788CF4MSRP = 11521.82	18X8	1	0	097
829-790CF3MSRP = 11452.55	18X10	1	0	097
829-792CF2MSRP = 11256.59	18X12	1	0	097
829-794CF2MSRP = 11079.89	18X14	1	0	097
829-796CFMSRP = 8088.12	18X16	1	0	097
829-814CF7MSRP = 11728.03	20X4	1	0	097
829-816CF6MSRP = 11609.86	20X6	1	0	097
829-818CF5MSRP = 11429.33	20X8	1	0	097
829-820CF4MSRP = 11174.84	20X10	1	0	097
829-822CF3MSRP = 16079.29	20X12	1	0	097
829-824CF3MSRP = 15851.31	20X14	1	0	097
829-826CF2MSRP = 13065.45	20X16	1	0	097
829-828CFMSRP = 12107.26	20X18	1	0	097
829-904CF8MSRP = 19236.03	24X4	1	0	097
829-906CF7MSRP = 19126.71	24X6	1	0	097
829-908CF6MSRP = 18928.87	24X8	1	0	097
829-910CF5MSRP = 33378.59	24X10	1	0	097
829-912CF4MSRP = 17966.80	24X12	1	0	097
829-914CF4MSRP = 27137.20	24X14	1	0	097
829-916CF3MSRP = 25169.79	24X16	1	0	097
829-918CF2MSRP = 26844.45	24X18	1	0	097
829-920CFMSRP = 24159.77	24X20	1	0	097

¹ Outlet Sized with Bushing

Made in the U.S.A.

Suitable for Oil-Free air handling to 25 psi, not for distribution of compressed air or gas

See Spears^® On-line Catalog @ www.spearsmfg.com for Pricing

Page 14

Schedule 80 CPVC Product
CPVC Schedule 80 Fittings

Print this Book

Couplings

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

Coupling - Reducer (continued)
Socket x Socket

¹ Outlet Sized with Bushing

Coupling - Eccentric Reducer
Socket x Socket

829-101CFEMSRP = 76.55	3/4X1/2	25	0	097
829-130CFEMSRP = 83.01	1X1/2	16	0	097
829-131CFEMSRP = 85.27	1X3/4	15	0	097
829-168CFEMSRP = 86.82	1-1/4X1	1	12	097
829-209CFE2MSRP = 137.48	1-1/2X1/2	1	10	097
829-210CFE2MSRP = 164.98	1-1/2X3/4	1	25	097
829-211CFEMSRP = 97.28	1-1/2X1	1	25	097
829-212CFEMSRP = 90.94	1-1/2X1-1/4	1	20	097
829-249CFEMSRP = 124.38	2X1	1	25	097
829-250CFEMSRP = 113.18	2X1-1/4	1	25	097
829-251CFEMSRP = 110.54	2X1-1/2	1	10	097
829-289CFE2MSRP = 231.87	2-1/2X1	1	12	097
829-290CFE2MSRP = 188.73	2-1/2X1-1/4	1	20	097
829-291CFE2MSRP = 188.34	2-1/2X1-1/2	1	20	097
829-292CFEMSRP = 133.73	2-1/2X2	1	10	097
829-335CFE2MSRP = 294.07	3X1	1	20	097
829-336CFE2MSRP = 280.83	3X1-1/4	1	10	097
829-337CFE2MSRP = 276.20	3X1-1/2	1	10	097
829-338ECMSRP = 340.21	3X2	15	0	090
829-338CFEMSRP = 179.08	3X2	1	20	097
829-339CFEMSRP = 359.59	3X2-1/2	1	10	097
829-417CFE3MSRP = 453.76	4X1	1	18	097
829-418CFE3MSRP = 462.04	4X1-1/4	1	6	097
829-419CFE3MSRP = 437.27	4X1-1/2	1	12	097
829-420CFE2MSRP = 400.18	4X2	1	10	097
829-421CFE2MSRP = 369.38	4X2-1/2	1	6	097
829-422CFEMSRP = 371.60	4X3	1	10	097
829-490CFEMSRP = 306.94	5X4	1	8	097
829-528CFE3MSRP = 808.73	6X2	1	6	097
829-529CFE3MSRP = 753.37	6X2-1/2	1	6	097
829-530CFE2MSRP = 645.93	6X3	1	6	097

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

Coupling - Eccentric Reducer (continued)
Socket x Socket

829-532CFEMSRP = 549.83	6X4	1	10	097
829-533CFEMSRP = 622.97	6X5	1	5	097
829-578CFE4MSRP = 2390.97	8X2	1	4	097
829-580CFE3MSRP = 1450.20	8X3	1	2	097
829-582CFE2MSRP = 1379.80	8X4	1	2	097
829-583CFE2MSRP = 1229.69	8X5	1	2	097
829-585CFEMSRP = 1196.63	8X6	1	4	097
829-624CFE3MSRP = 2864.15	10X4	1	0	097
829-625CFE3MSRP = 2536.14	10X5	1	0	097
829-626CFE2MSRP = 2455.62	10X6	1	2	097
829-628CFEMSRP = 1764.22	10X8	1	2	097
829-664CFE4MSRP = 5159.14	12X4	1	0	097
829-666CFE3MSRP = 3371.20	12X6	1	0	097
829-668CFE2MSRP = 3215.23	12X8	1	0	097
829-670CFEMSRP = 2877.33	12X10	1	0	097
829-696CFE3MSRP = 5581.02	14X6	1	0	097
829-698CFE2MSRP = 5472.06	14X8	1	0	097
829-700CFEMSRP = 3900.60	14X10	1	0	097
829-702CFEMSRP = 3561.17	14X12	1	0	097
829-756CFE4MSRP = 10193.91	16X6	1	0	097
829-758CFE3MSRP = 9856.19	16X8	1	0	097
829-760CFE2MSRP = 9675.29	16X10	1	0	097
829-762CFE2MSRP = 9294.95	16X12	1	0	097
829-764CFEMSRP = 8551.52	16X14	1	0	097
829-786CFE5MSRP = 19656.55	18X6	1	0	097
829-788CFE4MSRP = 19383.77	18X8	1	0	097
829-790CFE3MSRP = 18632.94	18X10	1	0	097
829-792CFE3MSRP = 17228.81	18X12	1	0	097
829-794CFE2MSRP = 16002.80	18X14	1	0	097
829-796CFEMSRP = 12266.88	18X16	1	0	097

Coupling
Fipt x Fipt

830-002CMSRP = 42.63	1/4	25	450	090
830-003CMSRP = 42.63	3/8	25	150	090
830-005CMSRP = 35.07	1/2	25	150	090

Page 15

Suitable for Oil-Free air handling to 25 psi, not for distribution of compressed air or gas

Spears^® Manufacturing Company

See Spears^® On-line Catalog @ www.spearsmfg.com for Pricing

Schedule 80 CPVC Product
CPVC Schedule 80 Fittings

Print this Book

Couplings

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

Coupling (continued)
Fipt x Fipt

830-010CMSRP = 64.34	1	15	90	090
830-012CMSRP = 68.23	1-1/4	10	60	090
830-015CMSRP = 73.33	1-1/2	10	80	090
830-020CMSRP = 86.44	2	10	0	090
830-025CMSRP = 155.09	2-1/2	5	0	090
830-030CMSRP = 201.61	3	5	0	090
830-040CMSRP = 368.02	4	5	0	090
830-060CFMSRP = 501.59	6	1	8	097
830-080CFMSRP = 764.84	8	1	6	097

Coupling - Special Reinforced
SR Fipt x SR Fipt - Stainless Steel Collar

830-005CSRMSRP = 19.24	1/2	25	150	096
830-007CSRMSRP = 31.07	3/4	25	150	096
830-010CSRMSRP = 35.33	1	25	200	096
830-012CSRMSRP = 37.52	1-1/4	10	120	096
830-015CSRMSRP = 40.22	1-1/2	10	80	096
830-020CSRMSRP = 47.55	2	10	0	096
830-030CSRMSRP = 189.85	3	10	0	096

Coupling - Reducer
Fipt x Fipt

830-072CMSRP = 47.28	1/2X1/4	50	400	090
830-073CMSRP = 47.28	1/2X3/8	25	150	090
830-101CMSRP = 57.48	3/4X1/2	50	200	090

Coupling - Special Reinforced Reducer
SR Fipt x SR Fipt - Stainless Steel Collar

830-101CSRMSRP = 34.46	3/4X1/2	50	200	096
830-130CSRMSRP = 41.64	1X1/2	50	0	096
830-131CSRMSRP = 41.64	1X3/4	25	200	096
830-168CSRMSRP = 56.63	1-1/4X1	25	0	096
830-210CSRMSRP = 80.97	1-1/2X3/4	25	0	096
830-211CSRMSRP = 80.97	1-1/2X1	10	80	096
830-212CSRMSRP = 80.97	1-1/2X1-1/4	10	80	096
830-249CSRMSRP = 199.35	2X1	25	0	096
830-251CSRMSRP = 199.35	2X1-1/2	15	0	096

Grooved Coupling Adapter
Groove x Socket

833-012CMSRP = 59.35	1-1/4	10	60	090
833-015CMSRP = 78.27	1-1/2	10	80	090
833-020CMSRP = 101.75	2	5	40	090

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

Grooved Coupling Adapter (continued)
Groove x Socket

833-025CMSRP = 167.31	2-1/2	5	0	090
833-030CMSRP = 206.31	3	5	0	090
833-040CMSRP = 351.05	4	5	0	090
833-050CFMSRP = 388.46	5	1	7	097
833-060CMSRP = 502.18	6	5	0	090
833-080CFMSRP = 633.35	8	1	4	097
833-100CFMSRP = 994.00	10	1	0	097
833-120CFMSRP = 1401.89	12	1	0	097

Adapters

Female Adapter
Socket x Fipt

835-002CMSRP = 43.06	1/4	25	450	090
835-003CMSRP = 43.06	3/8	25	150	090
835-098CMSRP = 28.49	3/4X1/4	25	150	090
835-005CMSRP = 21.33	1/2	25	150	090
835-007CMSRP = 28.52	3/4	15	90	090
835-010CMSRP = 52.02	1	15	90	090
835-012CMSRP = 53.29	1-1/4	10	120	090
835-015CMSRP = 62.06	1-1/2	10	80	090
835-020CMSRP = 106.98	2	10	0	090
835-025CMSRP = 205.19	2-1/2	5	0	090
835-030CMSRP = 421.03	3	5	0	090
835-040CMSRP = 700.80	4	5	0	090
835-060CMSRP = 994.93	6	6	0	090
835-060CFMSRP = 630.23	6	1	8	097
835-080CMSRP = 1572.01	8	3	0	090
835-080CFMSRP = 792.75	8	1	6	097
835-100CFMSRP = 1151.98	10	1	2	097
835-120CFMSRP = 1492.78	12	1	0	097

Female Adapter - Brass Transition
Socket x Fipt With Brass Thread Insert

835-005CBRMSRP = 65.41	1/2	25	150	096
835-007CBRMSRP = 135.40	3/4	15	90	096
835-010CBRMSRP = 237.62	1	15	90	096
835-012CBRMSRP = 387.64	1-1/4	15	60	096
835-015CBRMSRP = 511.06	1-1/2	10	40	096
835-020CBRMSRP = 638.33	2	8	32	096

Not intended to convey or dispense water for human consumption through drinking or cooking

Female Adapter - Brass Transition Reducing
Socket x Fipt With Brass Thread Insert

835-101CBRMSRP = 94.72

3/4X1/2

096

Made in the U.S.A.

Suitable for Oil-Free air handling to 25 psi, not for distribution of compressed air or gas

See Spears^® On-line Catalog @ www.spearsmfg.com for Pricing

Page 16

Schedule 80 CPVC Product
CPVC Schedule 80 Fittings

Print this Book

Adapters

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

Female Adapter - Brass Transition Reducing (continued)
Socket x Fipt With Brass Thread Insert

Not intended to convey or dispense water for human consumption through drinking or cooking

Female Adapter - Special Reinforced
Socket x SR Fipt - Stainless Steel Collar

835-002CSRMSRP = 35.45	1/4	25	450	096
835-003CSRMSRP = 26.98	3/8	25	300	096
835-005CSRMSRP = 11.60	1/2	25	150	096
835-007CSRMSRP = 12.54	3/4	25	150	096
835-010CSRMSRP = 28.59	1	25	200	096
835-012CSRMSRP = 29.35	1-1/4	10	60	096
835-015CSRMSRP = 34.02	1-1/2	10	80	096
835-020CSRMSRP = 48.38	2	10	0	096
835-025CSRMSRP = 112.44	2-1/2	5	0	096
835-030CSRMSRP = 231.06	3	15	0	096
835-040CSRMSRP = 384.57	4	5	0	096
835-060CSRMSRP = 600.76	6	6	0	096

Female Adapter - Special Reinforced Reducing
Socket x SR Fipt - Stainless Steel Collar

835-074CSRMSRP = 12.54	1/2X3/4	50	400	096
835-098CSRMSRP = 36.49	3/4X1/4	25	150	096
835-101CSRMSRP = 12.54	3/4X1/2	50	400	096
835-102CSRMSRP = 28.59	3/4X1	50	0	096
835-130CSRMSRP = 28.59	1X1/2	50	0	096
835-131CSRMSRP = 28.59	1X3/4	25	200	096

Female Adapter - Stainless Steel Transition
Socket x Fipt With Type 316 Stainless Steel Thread Insert
NSF_� Certified Lead Free

835-005CSSMSRP = 128.44	1/2	25	150	096
835-007CSSMSRP = 179.38	3/4	15	90	096
835-010CSSMSRP = 313.91	1	15	90	096
835-012CSSMSRP = 510.15	1-1/4	25	0	096
835-015CSSMSRP = 665.52	1-1/2	10	40	096
835-020CSSMSRP = 778.86	2	8	32	096

Female Adapter - Encapsulated Special Reinforced
Socket x ESR Fipt

835-002CESRMSRP = 34.28	1/4	25	450	096
835-003CESRMSRP = 34.28	3/8	25	300	096
835-005CESRMSRP = 17.80	1/2	25	300	096
835-007CESRMSRP = 18.78	3/4	25	300	096

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

Female Adapter - Encapsulated Special Reinforced (continued)
Socket x ESR Fipt

835-010CESRMSRP = 41.37	1	25	200	096
835-012CESRMSRP = 42.33	1-1/4	10	80	096
835-015CESRMSRP = 54.83	1-1/2	10	80	096
835-020CESRMSRP = 85.20	2	10	0	096

Male Adapter
Mipt x Socket

836-005CMSRP = 17.04	1/2	25	150	090
836-007CMSRP = 20.80	3/4	25	150	090
836-102CMSRP = 76.53	3/4X1	25	0	090
836-131CMSRP = 72.67	1X3/4	50	400	090
836-010CMSRP = 35.02	1	20	240	090
836-012CMSRP = 51.61	1-1/4	10	60	090
836-015CMSRP = 69.78	1-1/2	10	120	090
836-020CMSRP = 94.65	2	10	80	090
836-025CMSRP = 258.03	2-1/2	10	0	090
836-030CMSRP = 346.80	3	5	0	090
836-040CMSRP = 586.20	4	5	0	090
836-050CFMSRP = 639.22	5	1	8	097
836-060CMSRP = 840.19	6	5	0	090
836-060CFMSRP = 595.49	6	1	4	097
836-080CFMSRP = 760.24	8	1	2	097
836-100CFMSRP = 1408.65	10	1	2	097
836-120CFMSRP = 1559.36	12	1	0	097

Male Adapter - Internal Reinforced
R Mipt x Socket - Stainless Steel Sleeve
NSF_� Certified Lead Free

836-005CRMSRP = 17.82	1/2	25	150	096
836-007CRMSRP = 20.42	3/4	25	300	096
836-010CRMSRP = 24.23	1	10	120	096
836-012CRMSRP = 49.58	1-1/4	10	60	096
836-015CRMSRP = 66.88	1-1/2	10	40	096
836-020CRMSRP = 90.51	2	10	0	096

Male Adapter - CPVC Lined Brass Transition
Brass Mipt x Socket
NSF_� Certified Lead Free

836-005CBRMSRP = 145.03	1/2	40	160	096
836-007CBRMSRP = 204.20	3/4	40	160	096
836-010CBRMSRP = 355.62	1	10	60	096
836-012CBRMSRP = 578.44	1-1/4	10	40	096
836-015CBRMSRP = 752.03	1-1/2	10	40	096
836-020CBRMSRP = 881.23	2	8	32	096

Page 17

Suitable for Oil-Free air handling to 25 psi, not for distribution of compressed air or gas

Spears^® Manufacturing Company

See Spears^® On-line Catalog @ www.spearsmfg.com for Pricing

Schedule 80 CPVC Product
CPVC Schedule 80 Fittings

Print this Book

Adapters

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

Male Spigot Adapter
Spigot x Mipt

861-005CMSRP = 20.78	1/2	50	300	090
861-007CMSRP = 25.81	3/4	25	150	090
861-010CMSRP = 43.75	1	50	0	090
861-131CMSRP = 51.13	1X3/4	50	200	090
861-012CMSRP = 49.61	1-1/4	25	200	090
861-015CMSRP = 54.76	1-1/2	25	0	090
861-020CMSRP = 64.11	2	25	0	090

Female Spigot Adapter - Brass Transition
Spigot x Fipt With Brass Thread Insert

878-010CBRMSRP = 158.04

096

Not intended to convey or dispense water for human consumption through drinking or cooking

Female Spigot Adapter - Special Reinforced
Spigot x SR Fipt - Stainless Steel Collar

878-005CSRMSRP = 12.36	1/2	50	600	096
878-007CSRMSRP = 13.05	3/4	25	300	096
878-010CSRMSRP = 29.38	1	50	0	096
878-012CSRMSRP = 30.36	1-1/4	25	0	096
878-015CSRMSRP = 35.24	1-1/2	25	0	096
878-020CSRMSRP = 64.18	2	15	0	096
878-030CSRMSRP = 233.97	3	5	0	096
878-040CSRMSRP = 392.75	4	5	0	096

Female Spigot Adapter - Special Reinforced Reducing
Spigot x SR Fipt - Stainless Steel Collar

878-072CSRMSRP = 35.45	1/2X1/4	25	450	096
878-098CSRMSRP = 41.25	3/4X1/4	50	300	096
878-128CSRMSRP = 46.18	1X1/4	50	400	096

Female Spigot Adapter - Encapsulated Special Reinforced
Spigot x ESR Fipt

878-005CESRMSRP = 18.31	1/2	50	600	096
878-007CESRMSRP = 19.47	3/4	25	300	096
878-010CESRMSRP = 41.77	1	50	0	096
878-012CESRMSRP = 42.88	1-1/4	25	0	096
878-015CESRMSRP = 55.93	1-1/2	25	0	096
878-020CESRMSRP = 86.45	2	15	0	096

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

Female Spigot Adapter - Stainless Steel Transition
Spigot x Fipt With Type 316 Stainless Steel Thread Insert

878-005CSSMSRP = 127.27	1/2	25	150	096
878-007CSSMSRP = 163.72	3/4	25	150	096
878-010CSSMSRP = 212.45	1	15	90	096

Reducer Bushing

Reducer Bushing Flush Style
Spigot x Socket

837-052CMSRP = 27.59	3/8X1/4	50	450	090
837-072CMSRP = 27.59	1/2X1/4	50	300	090
837-073CMSRP = 27.59	1/2X3/8	50	300	090
837-101CMSRP = 14.07	3/4X1/2	50	300	090
837-129C1MSRP = 47.92	1X3/8	50	200	090
837-130CMSRP = 21.88	1X1/2	50	400	090
837-131CMSRP = 21.88	1X3/4	50	300	090
837-166CMSRP = 58.01	1-1/4X1/2	25	300	090
837-167CMSRP = 58.01	1-1/4X3/4	25	150	090
837-168CMSRP = 58.01	1-1/4X1	25	150	090
837-209CMSRP = 65.62	1-1/2X1/2	25	200	090
837-210CMSRP = 65.62	1-1/2X3/4	25	200	090
837-211CMSRP = 65.62	1-1/2X1	25	200	090
837-212CMSRP = 65.62	1-1/2X1-1/4	25	200	090
837-247CMSRP = 84.69	2X1/2	10	120	090
837-248CMSRP = 84.69	2X3/4	10	60	090
837-249CMSRP = 84.69	2X1	10	120	090
837-250CMSRP = 84.69	2X1-1/4	10	60	090
837-251CMSRP = 84.69	2X1-1/2	10	60	090
837-289CMSRP = 145.60	2-1/2X1	10	80	090
837-290CMSRP = 103.09	2-1/2X1-1/4	10	80	090
837-291CMSRP = 103.09	2-1/2X1-1/2	10	40	090
837-292CMSRP = 103.09	2-1/2X2	15	0	090
837-333CMSRP = 182.61	3X1/2	10	0	090
837-334C1MSRP = 179.60	3X3/4	10	0	090
837-335CMSRP = 157.09	3X1	10	0	090
837-336CMSRP = 157.09	3X1-1/4	10	0	090
837-337CMSRP = 157.09	3X1-1/2	10	0	090
837-338CMSRP = 157.09	3X2	10	0	090
837-339CMSRP = 157.09	3X2-1/2	15	0	090
837-416C1MSRP = 263.64	4X3/4	10	0	090
837-418C1MSRP = 282.46	4X1-1/4	6	0	090
837-419CMSRP = 263.66	4X1-1/2	6	0	090
837-420CMSRP = 173.71	4X2	6	0	090
837-421CMSRP = 173.71	4X2-1/2	6	0	090
837-422CMSRP = 173.71	4X3	6	0	090
837-486C1MSRP = 512.31	5X2	6	0	090
837-488C1MSRP = 512.31	5X3	5	0	090
837-490CMSRP = 328.35	5X4	4	0	090
837-490CFMSRP = 230.07	5X4	1	4	097

Made in the U.S.A.

Suitable for Oil-Free air handling to 25 psi, not for distribution of compressed air or gas

See Spears^® On-line Catalog @ www.spearsmfg.com for Pricing

Page 18

Schedule 80 CPVC Product
CPVC Schedule 80 Fittings

Print this Book

Reducer Bushing

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

Reducer Bushing Flush Style (continued)
Spigot x Socket

837-525C1MSRP = 466.73	6X1	5	0	090
837-527C1MSRP = 482.97	6X1-1/2	5	0	090
837-528CMSRP = 372.66	6X2	5	0	090
837-529C1MSRP = 540.57	6X2-1/2	5	0	090
837-530CMSRP = 372.66	6X3	5	0	090
837-532CMSRP = 370.07	6X4	5	0	090
837-533CFMSRP = 696.45	6X5	5	0	097
837-534CMSRP = 430.65	6X5	5	0	090
837-578C1MSRP = 1606.64	8X2	4	0	090
837-580C1MSRP = 1606.64	8X3	4	0	090
837-582CMSRP = 1606.64	8X4	4	0	090
837-583CFMSRP = 1946.48	8X5	4	0	097
837-585CMSRP = 1218.27	8X6	4	0	090
837-621C1MSRP = 2676.51	10X2	2	0	091
837-622C1MSRP = 2740.80	10X2-1/2	2	0	091
837-623C1MSRP = 2676.51	10X3	2	0	091
837-624C1MSRP = 2676.51	10X4	4	0	091
837-626CMSRP = 2156.21	10X6	3	0	091
837-628CMSRP = 2156.21	10X8	3	0	091
837-628CFMSRP = 1865.98	10X8	1	6	097
837-663CFMSRP = 3022.59	12X3	1	2	097
837-664C1MSRP = 4394.69	12X4	2	0	091
837-666CFMSRP = 2584.97	12X6	1	2	097
837-668CMSRP = 2718.49	12X8	2	0	091
837-670CFMSRP = 1946.48	12X10	1	3	097
837-696CFMSRP = 6823.46	14X6	1	0	097
837-698CFMSRP = 4757.05	14X8	1	3	097
837-700CFMSRP = 3862.52	14X10	3	0	097
837-702CFMSRP = 2799.05	14X12	3	0	097
837-754CFMSRP = 10920.39	16X4	1	0	097
837-756CFMSRP = 10757.41	16X6	1	0	097
837-758CFMSRP = 10055.19	16X8	1	0	097
837-760CFMSRP = 8039.23	16X10	1	0	097
837-762CFMSRP = 4089.83	16X12	2	0	097
837-764CFMSRP = 3894.59	16X14	1	2	097
837-786CFMSRP = 10687.22	18X6	1	0	097
837-788CFMSRP = 9915.70	18X8	1	0	097
837-790CFMSRP = 9721.56	18X10	1	0	097
837-792CFMSRP = 8397.15	18X12	1	0	097
837-794CFMSRP = 7168.82	18X14	1	0	097
837-796CFMSRP = 4347.92	18X16	1	0	097
837-816CFMSRP = 21982.51	20X6	1	0	097
837-818CFMSRP = 14349.44	20X8	1	0	097
837-820CFMSRP = 18022.54	20X10	1	0	097
837-822CFMSRP = 17253.81	20X12	1	0	097
837-824CFMSRP = 14993.59	20X14	1	0	097
837-826CFMSRP = 10612.53	20X16	1	0	097
837-828CFMSRP = 7048.95	20X18	1	0	097

¹ Sized with Bushing

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

Reducer Bushing Flush Style
Spigot x Fipt

838-052CMSRP = 29.66	3/8X1/4	50	450	090
838-071CMSRP = 29.66	1/2X1/8	50	300	090
838-072CMSRP = 29.66	1/2X1/4	50	600	090
838-073CMSRP = 29.66	1/2X3/8	50	300	090
838-098CMSRP = 33.06	3/4X1/4	50	300	090
838-099CMSRP = 33.06	3/4X3/8	50	600	090
838-101CMSRP = 15.35	3/4X1/2	50	600	090
838-129CMSRP = 43.91	1X3/8	50	400	090
838-130CMSRP = 19.46	1X1/2	50	400	090
838-131CMSRP = 19.46	1X3/4	50	400	090
838-166CMSRP = 62.83	1-1/4X1/2	25	150	090
838-167CMSRP = 62.83	1-1/4X3/4	25	300	090
838-168CMSRP = 62.83	1-1/4X1	25	300	090
838-207CMSRP = 77.40	1-1/2X1/4	25	200	090
838-209CMSRP = 77.40	1-1/2X1/2	25	200	090
838-210CMSRP = 77.40	1-1/2X3/4	25	200	090
838-211CMSRP = 77.40	1-1/2X1	25	200	090
838-212CMSRP = 77.40	1-1/2X1-1/4	25	200	090
838-247CMSRP = 106.41	2X1/2	10	120	090
838-248CMSRP = 106.41	2X3/4	10	60	090
838-249CMSRP = 106.41	2X1	10	120	090
838-250CMSRP = 106.41	2X1-1/4	10	120	090
838-251CMSRP = 106.41	2X1-1/2	10	120	090
838-287CMSRP = 170.22	2-1/2X1/2	10	0	090
838-288CMSRP = 170.22	2-1/2X3/4	10	40	090
838-289CMSRP = 170.22	2-1/2X1	10	40	090
838-290CMSRP = 170.22	2-1/2X1-1/4	10	0	090
838-291CMSRP = 169.06	2-1/2X1-1/2	10	40	090
838-292CMSRP = 169.06	2-1/2X2	10	40	090
838-334CMSRP = 450.44	3X3/4	10	0	090
838-335CMSRP = 450.44	3X1	10	0	090
838-336CMSRP = 394.01	3X1-1/4	10	0	090
838-337CMSRP = 394.01	3X1-1/2	10	0	090
838-338CMSRP = 376.87	3X2	10	0	090
838-339CMSRP = 379.93	3X2-1/2	10	0	090
838-420CMSRP = 767.97	4X2	6	0	090
838-421CMSRP = 767.97	4X2-1/2	6	0	090
838-422CMSRP = 767.97	4X3	6	0	090
838-528CMSRP = 1548.32	6X2	5	0	090
838-530CMSRP = 1548.32	6X3	5	0	090
838-532CMSRP = 1548.32	6X4	5	0	090

Reducer Bushing - Special Reinforced
Spigot x SR Fipt - Stainless Steel Collar

838-128CSRMSRP = 26.35	1X1/4	25	150	096
838-207CSRMSRP = 44.55	1-1/2X1/4	25	200	096
838-209CSRMSRP = 46.42	1-1/2X1/2	10	120	096
838-210CSRMSRP = 46.42	1-1/2X3/4	10	120	096

Page 19

Suitable for Oil-Free air handling to 25 psi, not for distribution of compressed air or gas

Spears^® Manufacturing Company

See Spears^® On-line Catalog @ www.spearsmfg.com for Pricing

Schedule 80 CPVC Product
CPVC Schedule 80 Fittings

Print this Book

Reducer Bushing

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

Reducer Bushing - Special Reinforced (continued)
Spigot x SR Fipt - Stainless Steel Collar

838-247CSRMSRP = 63.79	2X1/2	10	80	096
838-248CSRMSRP = 63.79	2X3/4	10	80	096
838-249CSRMSRP = 63.79	2X1	10	120	096
838-334CSRMSRP = 270.20	3X3/4	10	0	096
838-335CSRMSRP = 270.20	3X1	10	0	096
838-336CSRMSRP = 270.20	3X1-1/4	10	0	096
838-337CSRMSRP = 270.20	3X1-1/2	10	0	096
838-528CSRMSRP = 928.95	6X2	5	0	096
838-530CSRMSRP = 928.95	6X3	5	0	096
838-532CSRMSRP = 984.32	6X4	5	0	096

Reducer Bushing (T.T.) Flush Style
Mipt x Fipt

839-041CMSRP = 39.79	1/4X1/8	25	500	090
839-052CMSRP = 39.79	3/8X1/4	50	450	090
839-072CMSRP = 39.79	1/2X1/4	50	300	090
839-073CMSRP = 39.79	1/2X3/8	50	300	090
839-098CMSRP = 43.88	3/4X1/4	50	300	090
839-099CMSRP = 43.88	3/4X3/8	50	300	090
839-101CMSRP = 18.87	3/4X1/2	50	300	090
839-128CMSRP = 47.41	1X1/4	25	150	090
839-129CMSRP = 47.41	1X3/8	50	300	090
839-130CMSRP = 31.79	1X1/2	50	300	090
839-131CMSRP = 31.79	1X3/4	50	700	090
839-166CMSRP = 63.17	1-1/4X1/2	25	150	090
839-167CMSRP = 63.17	1-1/4X3/4	25	150	090
839-168CMSRP = 62.67	1-1/4X1	25	300	090
839-209CMSRP = 76.08	1-1/2X1/2	25	300	090
839-210CMSRP = 76.08	1-1/2X3/4	25	300	090
839-211CMSRP = 76.08	1-1/2X1	25	300	090
839-212CMSRP = 75.48	1-1/2X1-1/4	25	300	090
839-247CMSRP = 84.13	2X1/2	10	60	090
839-248CMSRP = 84.13	2X3/4	10	60	090
839-249CMSRP = 84.13	2X1	10	60	090
839-250CMSRP = 84.13	2X1-1/4	10	60	090
839-251CMSRP = 75.48	2X1-1/2	10	60	090
839-292CMSRP = 202.24	2-1/2X2	10	40	090
839-337CMSRP = 272.09	3X1-1/2	10	0	090
839-338CMSRP = 272.09	3X2	10	0	090
839-339CMSRP = 272.09	3X2-1/2	10	0	090
839-420CMSRP = 467.57	4X2	6	0	090
839-422CMSRP = 467.57	4X3	6	0	090
839-530CMSRP = 1687.92	6X3	5	0	090
839-532CMSRP = 1687.92	6X4	5	0	090

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

Reducer Bushing - Special Reinforced Reducing Flush Style
Mipt x SR Fipt - Stainless Steel Collar

839-209CSRMSRP = 45.69	1-1/2X1/2	25	300	096
839-210CSRMSRP = 45.69	1-1/2X3/4	25	300	096
839-247CSRMSRP = 50.51	2X1/2	10	60	096
839-248CSRMSRP = 50.51	2X3/4	10	60	096
839-249CSRMSRP = 50.51	2X1	10	120	096
839-420CSRMSRP = 280.53	4X2	6	0	096

Caps

Cap
Socket

847-002CMSRP = 22.71	1/4	25	450	090
847-003CMSRP = 22.71	3/8	25	450	090
847-005CMSRP = 20.55	1/2	50	300	090
847-007CMSRP = 29.28	3/4	25	300	090
847-010CMSRP = 51.80	1	15	90	090
847-012CMSRP = 56.65	1-1/4	10	60	090
847-015CMSRP = 56.65	1-1/2	10	60	090
847-020CMSRP = 59.79	2	10	80	090
847-025CMSRP = 201.22	2-1/2	5	40	090
847-030CMSRP = 220.55	3	5	0	090
847-040CMSRP = 224.22	4	5	0	090
847-050CFMSRP = 422.82	5	1	6	097
847-060CMSRP = 741.86	6	4	0	090
847-080CMSRP = 2251.37	8	3	0	090
847-100CFMSRP = 1880.91	10	1	5	097
847-120CFMSRP = 2061.41	12	1	4	097
847-140CFMSRP = 6323.14	14	1	2	097
847-160CFMSRP = 9299.71	16	1	2	097
847-180CFMSRP = 11465.86	18	1	0	097
847-200CFMSRP = 15434.44	20	1	0	097
847-240CFMSRP = 29456.04	24	1	0	097

Cap
Fipt

848-002CMSRP = 26.57	1/4	25	450	090
848-003CMSRP = 26.57	3/8	25	450	090
848-005CMSRP = 22.82	1/2	25	150	090
848-007CMSRP = 37.77	3/4	25	300	090
848-010CMSRP = 52.91	1	15	90	090
848-012CMSRP = 94.33	1-1/4	10	60	090
848-015CMSRP = 96.65	1-1/2	10	120	090
848-020CMSRP = 139.22	2	10	80	090
848-025CMSRP = 322.14	2-1/2	5	40	090
848-030CMSRP = 422.61	3	5	0	090
848-040CMSRP = 613.87	4	5	0	090

Made in the U.S.A.

Suitable for Oil-Free air handling to 25 psi, not for distribution of compressed air or gas

See Spears^® On-line Catalog @ www.spearsmfg.com for Pricing

Page 20

Schedule 80 CPVC Product
CPVC Schedule 80 Fittings

Print this Book

Caps

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

Cap (continued)
Fipt

848-060CFMSRP = 868.53	6	1	4	097
848-080CFMSRP = 942.41	8	1	3	097
848-100CFMSRP = 1927.86	10	1	2	097
848-120CFMSRP = 3351.82	12	1	2	097

Cap - Special Reinforced
SR Fipt - Stainless Steel Collar

848-002CSRMSRP = 14.60	1/4	25	500	096
848-003CSRMSRP = 14.60	3/8	25	450	096
848-005CSRMSRP = 13.05	1/2	50	300	096
848-007CSRMSRP = 22.75	3/4	25	300	096
848-030CSRMSRP = 253.88	3	5	0	096

Plugs

Plug
Spigot

849-005CMSRP = 26.18	1/2	50	300	090
849-007CMSRP = 32.27	3/4	50	300	090
849-010CMSRP = 36.43	1	50	200	090
849-012CMSRP = 46.42	1-1/4	25	100	090
849-015CMSRP = 50.97	1-1/2	10	120	090
849-020CMSRP = 68.28	2	10	120	090
849-025CF4MSRP = 80.96	2-1/2	4	0	097
849-030CF4MSRP = 186.18	3	4	0	097
849-040CF4MSRP = 229.76	4	4	0	097
849-060CF4MSRP = 285.22	6	1	6	097
849-080CF4MSRP = 766.14	8	1	6	097
849-100CF4MSRP = 1524.32	10	1	2	097
849-120CF4MSRP = 2954.39	12	1	0	097
849-140CF4MSRP = 6636.82	14	1	0	097
849-160CF4MSRP = 8572.71	16	1	0	097
849-180CF4MSRP = 11371.60	18	1	0	097
849-200CF4MSRP = 22570.11	20	1	0	097
849-240CF4MSRP = 31209.77	24	1	0	097

⁴ Plug fabricated using Cap and pipe spigot.

Plug
Mipt

850-002CMSRP = 21.35	1/4	50	900	090
850-003CMSRP = 21.35	3/8	50	450	090
850-005CMSRP = 18.56	1/2	50	500	090
850-007CMSRP = 23.49	3/4	50	300	090
850-010CMSRP = 38.67	1	25	175	090

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

Plug (continued)
Mipt

850-012CMSRP = 43.97	1-1/4	25	150	090
850-015CMSRP = 48.45	1-1/2	25	150	090
850-020CMSRP = 65.98	2	10	120	090
850-025CMSRP = 112.01	2-1/2	5	30	090
850-030CMSRP = 119.94	3	5	40	090
850-040CMSRP = 212.83	4	5	0	090
850-060CMSRP = 298.87	6	6	0	090
850-060CF4MSRP = 771.73	6	1	2	097
850-080CMSRP = 531.08	8	6	0	090
850-080CF4MSRP = 1481.77	8	1	2	097
850-100CF4MSRP = 2138.73	10	1	3	097
850-120CF4MSRP = 3262.21	12	1	0	097

⁴ Plug fabricated using Cap and threaded pipe.

Wyes

Wye
Socket x Socket x Socket
1/2" - 2" - 235 psi Maximum Internal Pressure Rating @ 73�F (23�C) 2-1/2" - 6" - 150 psi Maximum Internal Pressure Rating @ 73�F (23�C) 8" -10" & All Fabricated Sizes - 100 psi Maximum Internal Pressure Rating @ 73�F (23�C) 12" 80 psi Maximum Internal Pressure Rating @ 73�F (23�C)

875-005CMSRP = 33.94	1/2	25	100	090
875-007CMSRP = 35.05	3/4	25	0	090
875-010CMSRP = 59.05	1	20	0	090
875-012CMSRP = 89.45	1-1/4	20	0	090
875-015CMSRP = 96.13	1-1/2	20	0	090
875-020CMSRP = 235.40	2	10	0	090
875-025CMSRP = 750.13	2-1/2	6	0	090
875-030CMSRP = 1160.73	3	5	0	090
875-040CMSRP = 1227.18	4	4	0	090
875-060CMSRP = 1679.60	6	3	0	090
875-080CMSRP = 2868.40	8	1	0	090
875-080CF2MSRP = 2508.81	8	1	0	097
875-100CF2MSRP = 4309.85	10	1	0	097
875-120CF2MSRP = 6002.97	12	1	0	097
875-140CF2MSRP = 20870.82	14	1	0	097
875-160CF2MSRP = 26178.84	16	1	0	097
875-180CF2MSRP = 37988.51	18	1	0	097
875-200CF2MSRP = 44121.68	20	1	0	097
875-240CF2MSRP = 56374.12	24	1	0	097

² Fiberglass reinforced

Page 21

Suitable for Oil-Free air handling to 25 psi, not for distribution of compressed air or gas

Spears^® Manufacturing Company

See Spears^® On-line Catalog @ www.spearsmfg.com for Pricing

Schedule 80 CPVC Product
CPVC Schedule 80 Fittings

Print this Book

Wyes

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

Wye - Reducing
Socket x Socket x Socket
1/2" - 2" - 235 psi Maximum Internal Pressure Rating @ 73�F (23�C) 2-1/2" - 6" - 150 psi Maximum Internal Pressure Rating @ 73�F (23�C) 8" -10" & All Fabricated Sizes - 100 psi Maximum Internal Pressure Rating @ 73�F (23�C) 12" 80 psi Maximum Internal Pressure Rating @ 73�F (23�C)

875-101C1MSRP = 50.11	3/4X1/2	25	0	090
875-130C1MSRP = 82.57	1X1/2	20	0	090
875-131C1MSRP = 82.57	1X3/4	20	0	090
875-166C1MSRP = 150.46	1-1/4X1/2	20	0	090
875-167C1MSRP = 150.46	1-1/4X3/4	20	0	090
875-168C1MSRP = 150.46	1-1/4X1	20	0	090
875-209C1MSRP = 165.07	1-1/2X1/2	20	0	090
875-210C1MSRP = 165.07	1-1/2X3/4	20	0	090
875-211C1MSRP = 165.07	1-1/2X1	20	0	090
875-212C1MSRP = 165.07	1-1/2X1-1/4	20	0	090
875-247C1MSRP = 326.61	2X1/2	10	0	090
875-248C1MSRP = 326.61	2X3/4	10	0	090
875-249C1MSRP = 326.61	2X1	10	0	090
875-250C1MSRP = 326.61	2X1-1/4	10	0	090
875-251C1MSRP = 326.61	2X1-1/2	10	0	090
875-335C1MSRP = 1343.49	3X1	5	0	090
875-336C1MSRP = 1343.49	3X1-1/4	5	0	090
875-337C1MSRP = 1343.49	3X1-1/2	5	0	090
875-338C1MSRP = 1343.49	3X2	4	0	090
875-339C1MSRP = 1343.49	3X2-1/2	5	0	090
875-420CMSRP = 1358.54	4X2	4	0	090
875-421C1MSRP = 1429.52	4X2-1/2	4	0	090
875-422CMSRP = 1358.54	4X3	4	0	090
875-528C1MSRP = 1720.75	6X2	5	0	090
875-528CF2MSRP = 1350.03	6X2	1	3	097
875-530C1MSRP = 1720.39	6X3	5	0	090
875-530CF2MSRP = 1501.03	6X3	1	2	097
875-532CMSRP = 1313.65	6X4	5	0	090
875-578C1MSRP = 4550.35	8X2	2	0	090
875-578CF2MSRP = 1814.84	8X2	1	2	097
875-579CF2MSRP = 1902.14	8X2-1/2	1	2	097
875-580C1MSRP = 4550.35	8X3	2	0	090
875-580CF2MSRP = 1859.98	8X3	1	2	097
875-582CMSRP = 4550.35	8X4	2	0	090
875-582CF2MSRP = 1910.23	8X4	1	2	097
875-585C1MSRP = 4170.06	8X6	1	0	090
875-585CF2MSRP = 2653.52	8X6	1	0	097
875-621CF2MSRP = 2021.72	10X2	1	0	097
875-623CF2MSRP = 2152.31	10X3	1	0	097
875-624CF2MSRP = 2630.25	10X4	1	0	097
875-626CMSRP = 4700.81	10X6	1	0	091
875-626CF2MSRP = 2986.46	10X6	1	0	097

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

Wye - Reducing (continued)
Socket x Socket x Socket

875-628CMSRP = 4949.47	10X8	1	091
875-628CF2MSRP = 3516.85	10X8	1	097
875-661CF2MSRP = 3335.68	12X2	1	097
875-663CF2MSRP = 3504.41	12X3	1	097
875-664CF2MSRP = 3997.52	12X4	1	097
875-666CF2MSRP = 4158.51	12X6	1	097
875-668CF2MSRP = 4389.29	12X8	1	097
875-670CF2MSRP = 5404.07	12X10	1	097
875-694CF2MSRP = 8947.58	14X4	1	097
875-696CF2MSRP = 9827.68	14X6	1	097
875-698CF2MSRP = 10631.06	14X8	1	097
875-700CF2MSRP = 12390.42	14X10	1	097
875-702CF2MSRP = 12951.09	14X12	1	097
875-754CF2MSRP = 11258.71	16X4	1	097
875-756CF2MSRP = 11854.86	16X6	1	097
875-758CF2MSRP = 13765.24	16X8	1	097
875-760CF2MSRP = 15470.20	16X10	1	097
875-762CF2MSRP = 16778.19	16X12	1	097
875-764CF2MSRP = 19932.60	16X14	1	097
875-784CF2MSRP = 11638.04	18X4	1	097
875-786CF2MSRP = 12791.33	18X6	1	097
875-788CF2MSRP = 14754.86	18X8	1	097
875-790CF2MSRP = 16290.59	18X10	1	097
875-792CF2MSRP = 18540.47	18X12	1	097
875-794CF2MSRP = 20338.09	18X14	1	097
875-796CF2MSRP = 21533.36	18X16	1	097

¹ Sized with Bushing
² Fiberglass reinforced

Double Wye
Socket x Socket x Socket x Socket
100 psi Maximum internal Pressure Rating @ 73�F (23�C)

876-020CF2MSRP = 977.02	2	1	4	097
876-030CF2MSRP = 1246.17	3	1	4	097
876-040CF2MSRP = 2136.69	4	1	2	097
876-060CF2MSRP = 3725.34	6	1	0	097
876-080CF2MSRP = 6681.22	8	1	0	097
876-100CF2MSRP = 7250.59	10	1	0	097
876-120CF2MSRP = 10863.19	12	1	0	097

² Fiberglass reinforced
For larger sizes please contact your Regional Spears^� Distribution Center.

Double Wye - Reducing
Socket x Socket x Socket x Socket
Size 3" is 150 psi, all Fabricated Sizes- 100 psi Maximum Internal Pressure Rating @ 73�F (23�C)

876-338CMSRP = 1447.26	3X2	5	0	090
876-420CF2MSRP = 1820.63	4X2	1	2	097
876-421CF2MSRP = 1926.71	4X2-1/2	1	2	097

Made in the U.S.A.

Suitable for Oil-Free air handling to 25 psi, not for distribution of compressed air or gas

See Spears^® On-line Catalog @ www.spearsmfg.com for Pricing

Page 22

Schedule 80 CPVC Product
CPVC Schedule 80 Fittings

Print this Book

Wyes

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

Double Wye - Reducing (continued)
Socket x Socket x Socket x Socket

876-422CF2MSRP = 2074.38	4X3	1	2	097
876-528CF2MSRP = 3096.42	6X2	1	3	097
876-529CF2MSRP = 3134.96	6X2-1/2	1	2	097
876-530CF2MSRP = 3185.99	6X3	1	2	097
876-532CF2MSRP = 3538.09	6X4	1	0	097
876-578CF2MSRP = 5291.59	8X2	1	2	097
876-579CF2MSRP = 5369.77	8X2-1/2	1	2	097
876-580CF2MSRP = 5412.29	8X3	1	0	097
876-582CF2MSRP = 5826.73	8X4	1	0	097
876-585CF2MSRP = 6142.65	8X6	1	0	097
876-621CF2MSRP = 6379.81	10X2	1	0	097
876-622CF2MSRP = 6512.87	10X2-1/2	1	0	097
876-623CF2MSRP = 6628.46	10X3	1	0	097
876-624CF2MSRP = 6781.71	10X4	1	0	097
876-626CF2MSRP = 7261.28	10X6	1	0	097
876-628CF2MSRP = 7626.71	10X8	1	0	097
876-661CF2MSRP = 6868.69	12X2	1	0	097
876-662CF2MSRP = 7197.99	12X2-1/2	1	0	097
876-663CF2MSRP = 7324.99	12X3	1	0	097
876-664CF2MSRP = 7593.22	12X4	1	0	097
876-666CF2MSRP = 8311.15	12X6	1	0	097
876-668CF2MSRP = 9429.39	12X8	1	0	097
876-670CF2MSRP = 10267.17	12X10	1	0	097

² Fiberglass reinforced
For larger sizes please contact your Regional Spears^� Distribution Center.

Unions

Union 2000 - Socket/FKM
Socket x Socket with FKM O-ring Seal
1/4" - 4" 235 psi; 6" 150 psi Maximum Internal Pressure Rating @ 73�F (23�C)

857-002CMSRP = 85.09	1/4	25	150	090
857-003CMSRP = 85.09	3/8	25	150	090
8057-005CMSRP = 56.62	1/2	20	120	090
8057-007CMSRP = 59.15	3/4	20	80	090
8057-010CMSRP = 71.01	1	15	90	090
8057-012CMSRP = 143.62	1-1/4	10	0	090
8057-015CMSRP = 146.23	1-1/2	10	0	090
8057-020CMSRP = 242.43	2	5	0	090
8057-025CMSRP = 397.56	2-1/2	5	0	090
8057-030CMSRP = 503.15	3	5	0	090
8057-040CMSRP = 642.81	4	4	0	090
8057-060CMSRP = 1428.51	6	1	0	090

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

Union 2000 - Socket/EPDM
Socket x Socket with EPDM O-ring Seal
1/2" - 4" 235 psi; 6" 150 psi Maximum Internal Pressure Rating @ 73�F (23�C)

897-002CMSRP = 84.07	1/4	25	150	090
897-003CMSRP = 84.07	3/8	25	150	090
8097-005CMSRP = 56.43	1/2	20	120	090
8097-007CMSRP = 58.45	3/4	20	80	090
8097-010CMSRP = 70.01	1	15	90	090
8097-012CMSRP = 141.78	1-1/4	10	0	090
8097-015CMSRP = 144.45	1-1/2	10	0	090
8097-020CMSRP = 239.44	2	5	0	090
8097-025CMSRP = 396.52	2-1/2	5	0	090
8097-030CMSRP = 496.97	3	5	0	090
8097-040CMSRP = 635.54	4	4	0	090
8097-060CMSRP = 1412.27	6	1	0	090

Union 2000 - Socket/Fipt/FKM
Socket x Fipt with FKM O-ring Seal
1/2" - 4" 235 psi; 6" 150 psi Maximum Internal Pressure Rating @ 73�F (23�C)

8059-005CMSRP = 64.43	1/2	20	120	090
8059-007CMSRP = 112.44	3/4	20	80	090
8059-010CMSRP = 155.24	1	15	90	090
8059-012CMSRP = 263.43	1-1/4	10	0	090
8059-015CMSRP = 295.67	1-1/2	10	0	090
8059-020CMSRP = 334.27	2	5	0	090
8059-025CMSRP = 542.64	2-1/2	5	0	090
8059-030CMSRP = 641.83	3	5	0	090
8059-040CMSRP = 742.17	4	4	0	090
8059-060CMSRP = 1429.73	6	1	0	090

Union 2000 - Socket/Fipt/EPDM
Socket x Fipt with EPDM O-ring Seal
1/2" - 4" 235 psi; 6" 150 psi Maximum Internal Pressure Rating @ 73�F (23�C)

8099-005CMSRP = 62.84	1/2	20	120	090
8099-007CMSRP = 111.14	3/4	20	80	090
8099-010CMSRP = 153.28	1	15	90	090
8099-012CMSRP = 292.01	1-1/4	10	0	090
8099-015CMSRP = 292.01	1-1/2	10	0	090
8099-020CMSRP = 330.09	2	5	0	090
8099-025CMSRP = 472.88	2-1/2	5	0	090
8099-030CMSRP = 633.94	3	5	0	090
8099-040CMSRP = 731.28	4	4	0	090
8099-060CMSRP = 1365.07	6	1	0	090

Page 23

Suitable for Oil-Free air handling to 25 psi, not for distribution of compressed air or gas

Spears^® Manufacturing Company

See Spears^® On-line Catalog @ www.spearsmfg.com for Pricing

Schedule 80 CPVC Product
CPVC Schedule 80 Fittings

Print this Book

Unions

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

Union 2000 - Socket/Spigot/FKM
Socket x Spigot with FKM O-ring Seal
1/2" - 4" 235 psi; 6" 150 psi Maximum Internal Pressure Rating @ 73�F (23�C)

8056-005CMSRP = 56.62	1/2	20	160	090
8056-007CMSRP = 59.15	3/4	20	160	090
8056-010CMSRP = 71.01	1	15	90	090
8056-012CMSRP = 143.62	1-1/4	10	0	090
8056-015CMSRP = 146.23	1-1/2	10	0	090
8056-020CMSRP = 242.43	2	5	0	090
8056-025CMSRP = 442.94	2-1/2	5	0	090
8056-030CMSRP = 503.15	3	5	0	090
8056-040CMSRP = 642.81	4	4	0	090
8056-060CMSRP = 1428.51	6	1	0	090

Union 2000 - Socket/Spigot/EPDM
Socket x Spigot with EPDM O-ring Seal
1/2" - 4" 235 psi; 6" 150 psi Maximum Internal Pressure Rating @ 73�F (23�C)

8096-005CMSRP = 56.43	1/2	20	160	090
8096-007CMSRP = 58.45	3/4	20	80	090
8096-010CMSRP = 70.01	1	15	90	090
8096-012CMSRP = 141.78	1-1/4	10	0	090
8096-015CMSRP = 144.45	1-1/2	10	0	090
8096-020CMSRP = 239.44	2	5	0	090
8096-025CMSRP = 396.52	2-1/2	5	0	090
8096-030CMSRP = 496.97	3	5	0	090
8096-040CMSRP = 635.54	4	4	0	090
8096-060CMSRP = 1412.27	6	1	0	090

Union 2000 - Fipt/Mipt/FKM
Fipt x Mipt with FKM O-ring Seal
1/2" - 3" 235 psi Maximum Internal Pressure Rating @ 73�F (23�C)

8053-005CMSRP = 56.62	1/2	20	120	090
8053-007CMSRP = 59.15	3/4	20	0	090
8053-010CMSRP = 71.01	1	15	90	090
8053-012CMSRP = 143.62	1-1/4	10	0	090
8053-015CMSRP = 146.23	1-1/2	10	0	090
8053-020CMSRP = 242.43	2	5	0	090
8053-030CMSRP = 503.15	3	5	0	090

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

Union 2000 - Fipt/Mipt/EPDM
Fipt x Mipt with EPDM O-ring Seal
1/2" - 3" 235 psi Maximum Internal Pressure Rating @ 73�F (23�C)

8093-005CMSRP = 56.43	1/2	20	120	090
8093-007CMSRP = 58.45	3/4	20	0	090
8093-010CMSRP = 70.01	1	15	90	090
8093-012CMSRP = 141.78	1-1/4	10	0	090
8093-015CMSRP = 144.45	1-1/2	10	0	090
8093-020CMSRP = 239.44	2	5	0	090
8093-030CMSRP = 496.97	3	5	0	090

Union 2000 - Fipt/Mipt/FKM- Reducing
Fipt x Mipt with FKM O-ring Seal
235 psi Maximum Internal Pressure Rating @ 73�F (23�C)

8053-168CMSRP = 160.94

1-1/4X1

090

Union 2000 - Fipt/Mipt/EPDM-Reducing
Fipt x Mipt with EPDM O-ring Seal
235 psi Maximum Internal Pressure Rating @ 73�F (23�C)

8093-168CMSRP = 158.42

1-1/4X1

090

Union 2000 - Socket/Mipt/FKM
Socket x Mipt with FKM O-ring Seal
1/2" - 3" 235 psi Maximum Internal Pressure Rating @ 73�F (23�C)

8054-005CMSRP = 56.62	1/2	20	120	090
8054-007CMSRP = 59.15	3/4	20	0	090
8054-010CMSRP = 71.01	1	15	90	090
8054-012CMSRP = 143.62	1-1/4	10	0	090
8054-015CMSRP = 146.23	1-1/2	10	0	090
8054-020CMSRP = 242.43	2	5	0	090
8054-030CMSRP = 503.15	3	5	0	090

Union 2000 - Socket/Mipt/EPDM
Socket x Mipt with EPDM O-ring Seal
1/2" - 3" 235 psi Maximum Internal Pressure Rating @ 73�F (23�C)

8094-005CMSRP = 56.43	1/2	20	120	090
8094-007CMSRP = 58.45	3/4	20	80	090
8094-010CMSRP = 70.01	1	15	90	090
8094-012CMSRP = 141.78	1-1/4	10	0	090
8094-015CMSRP = 144.45	1-1/2	10	0	090
8094-020CMSRP = 239.44	2	5	0	090

Made in the U.S.A.

Suitable for Oil-Free air handling to 25 psi, not for distribution of compressed air or gas

See Spears^® On-line Catalog @ www.spearsmfg.com for Pricing

Page 24

Schedule 80 CPVC Product
CPVC Schedule 80 Fittings

Print this Book

Unions

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

Union 2000 - Socket/Mipt/EPDM (continued)
Socket x Mipt with EPDM O-ring Seal

8094-030CMSRP = 496.97

090

Union 2000 - Socket/Mipt/FKM-Reducing
Socket x Mipt with FKM O-ring Seal
235 psi Maximum Internal Pressure Rating @ 73�F (23�C)

8054-168CMSRP = 160.94

1-1/4X1

090

Union 2000 - Socket/Mipt/EPDM -Reducing
Socket x Mipt with EPDM O-ring Seal
235 psi Maximum Internal Pressure Rating @ 73�F (23�C)

8094-168CMSRP = 158.42

1-1/4X1

090

Union 2000 - Special Reinforced Fipt/Spigot/FKM
SR Fipt x Spigot with FKM O-ring Seal
1/2" - 4" 235 psi; 6" 150 psi Maximum Internal Pressure Rating @ 73�F (23�C)

8055-005CSRMSRP = 74.52	1/2	20	160	096
8055-007CSRMSRP = 78.41	3/4	20	160	096
8055-010CSRMSRP = 99.96	1	15	90	096
8055-012CSRMSRP = 160.63	1-1/4	10	0	096
8055-015CSRMSRP = 183.89	1-1/2	10	0	096
8055-020CSRMSRP = 282.52	2	5	0	096
8055-025CSRMSRP = 533.23	2-1/2	5	0	096
8055-030CSRMSRP = 563.47	3	5	0	096
8055-040CSRMSRP = 727.86	4	4	0	096
8055-060CSRMSRP = 865.87	6	1	0	096

Union 2000 - Special Reinforced Fipt/Spigot/EPDM
SR Fipt x Spigot with EPDM O-ring Seal
1/2" - 4" 235 psi; 6" 150 psi Maximum Internal Pressure Rating @ 73�F (23�C)

8095-005CSRMSRP = 73.83	1/2	20	120	096
8095-007CSRMSRP = 76.36	3/4	20	160	096
8095-010CSRMSRP = 97.93	1	15	90	096
8095-012CSRMSRP = 150.43	1-1/4	10	0	096
8095-015CSRMSRP = 170.85	1-1/2	10	0	096
8095-020CSRMSRP = 257.82	2	5	0	096
8095-025CSRMSRP = 511.71	2-1/2	5	0	096
8095-030CSRMSRP = 551.65	3	5	0	096
8095-040CSRMSRP = 696.11	4	4	0	096
8095-060CSRMSRP = 844.61	6	1	0	096

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

Union 2000 - Fipt/FKM
Fipt x Fipt with FKM O-ring Seal
1/4" - 4" 235 psi; 6" 150 psi Maximum Internal Pressure Rating @ 73�F (23�C)

858-002CMSRP = 95.67	1/4	25	150	090
858-003CMSRP = 95.67	3/8	25	150	090
8058-005CMSRP = 60.61	1/2	20	120	090
8058-007CMSRP = 107.16	3/4	20	80	090
8058-010CMSRP = 147.78	1	15	90	090
8058-012CMSRP = 281.57	1-1/4	10	0	090
8058-015CMSRP = 281.57	1-1/2	10	0	090
8058-020CMSRP = 318.29	2	5	0	090
8058-025CMSRP = 512.75	2-1/2	5	0	090
8058-030CMSRP = 972.97	3	5	0	090
8058-040CMSRP = 1045.85	4	4	0	090
8058-060CMSRP = 1493.60	6	1	0	090

Union 2000 - Fipt/EPDM
Fipt x Fipt with EPDM O-ring Seal
1/4" - 4" 235 psi; 6" 150 psi Maximum Internal Pressure Rating @ 73�F (23�C)

898-002CMSRP = 94.54	1/4	25	150	090
898-003CMSRP = 94.54	3/8	25	100	090
8098-005CMSRP = 59.87	1/2	20	120	090
8098-007CMSRP = 105.86	3/4	20	80	090
8098-010CMSRP = 145.97	1	15	90	090
8098-012CMSRP = 278.33	1-1/4	10	0	090
8098-015CMSRP = 278.33	1-1/2	10	0	090
8098-020CMSRP = 314.40	2	5	0	090
8098-025CMSRP = 442.94	2-1/2	5	0	090
8098-030CMSRP = 881.25	3	5	0	090
8098-040CMSRP = 1025.97	4	4	0	090
8098-060CMSRP = 1436.06	6	1	0	090

Union 2000 - Socket/Special Reinforced Fipt/FKM
Socket x SR Fipt with FKM O-ring Seal
1/2" - 4" 235 psi; 6" 150 psi Maximum Internal Pressure Rating @ 73�F (23�C)

8059-005CSRMSRP = 33.36	1/2	20	120	096
8059-007CSRMSRP = 58.85	3/4	20	160	096
8059-010CSRMSRP = 81.06	1	15	90	096
8059-012CSRMSRP = 154.54	1-1/4	10	0	096
8059-015CSRMSRP = 168.00	1-1/2	10	0	096
8059-020CSRMSRP = 174.87	2	5	0	096
8059-025CSRMSRP = 302.82	2-1/2	5	0	096
8059-030CSRMSRP = 491.99	3	5	0	096
8059-040CSRMSRP = 573.99	4	4	0	096
8059-060CSRMSRP = 1572.60	6	1	0	096

Page 25

Suitable for Oil-Free air handling to 25 psi, not for distribution of compressed air or gas

Spears^® Manufacturing Company

See Spears^® On-line Catalog @ www.spearsmfg.com for Pricing

Schedule 80 CPVC Product
CPVC Schedule 80 Fittings

Print this Book

Unions

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

Union 2000 - Socket/Special Reinforced Fipt/EPDM
Socket x SR Fipt w/EPDM O-ring Seal - Stainless Steel Collar
1/2" - 4" 235 psi; 6" 150 psi Maximum Internal Pressure Rating @ 73�F (23�C)

8099-005CSRMSRP = 32.71	1/2	20	120	096
8099-007CSRMSRP = 58.03	3/4	20	160	096
8099-010CSRMSRP = 80.39	1	15	90	096
8099-012CSRMSRP = 152.27	1-1/4	10	0	096
8099-015CSRMSRP = 165.62	1-1/2	10	0	096
8099-020CSRMSRP = 174.41	2	5	0	096
8099-025CSRMSRP = 299.13	2-1/2	5	0	096
8099-030CSRMSRP = 485.80	3	5	0	096
8099-040CSRMSRP = 570.54	4	4	0	096
8099-060CSRMSRP = 1532.95	6	1	0	096

Union 2000 - Special Reinforced Fipt/FKM
SR Fipt x SR Fipt w/FKM O-ring Seal - Stainless Steel Collar
1/2" - 4" 235 psi; 6" 150 psi Maximum Internal Pressure Rating @ 73�F (23�C)

8058-005CSRMSRP = 34.23	1/2	20	120	096
8058-007CSRMSRP = 59.64	3/4	20	80	096
8058-010CSRMSRP = 81.98	1	15	90	096
8058-012CSRMSRP = 154.54	1-1/4	10	0	096
8058-015CSRMSRP = 168.65	1-1/2	10	0	096
8058-020CSRMSRP = 177.69	2	5	0	096
8058-025CSRMSRP = 307.62	2-1/2	5	0	096
8058-030CSRMSRP = 502.14	3	5	0	096
8058-040CSRMSRP = 588.24	4	4	0	096
8058-060CSRMSRP = 1579.19	6	1	0	096

Union 2000 - Special Reinforced Fipt/EPDM
SR Fipt x SR Fipt w/EPDM O-ring Seal - Stainless Steel Collar
1/2" - 4" 235 psi; 6" 150 psi Maximum Internal Pressure Rating @ 73�F (23�C)

8098-005CSRMSRP = 33.07	1/2	20	160	096
8098-007CSRMSRP = 59.09	3/4	20	80	096
8098-010CSRMSRP = 81.06	1	15	90	096
8098-012CSRMSRP = 153.03	1-1/4	10	0	096
8098-015CSRMSRP = 167.33	1-1/2	10	0	096
8098-020CSRMSRP = 175.93	2	5	0	096
8098-025CSRMSRP = 304.07	2-1/2	5	0	096
8098-030CSRMSRP = 494.35	3	5	0	096
8098-040CSRMSRP = 572.33	4	4	0	096
8098-060CSRMSRP = 1552.15	6	1	0	096

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

Union (Old Style) - Socket/FKM
Socket x Socket with FKM O-ring Seal
235 psi Maximum Internal Pressure Rating @ 73�F (23�C)

857-005CMSRP = 56.62	1/2	15	90	090
857-007CMSRP = 59.15	3/4	10	60	090
857-010CMSRP = 71.01	1	10	40	090
857-012CMSRP = 143.62	1-1/4	5	20	090
857-015CMSRP = 146.23	1-1/2	5	0	090
857-020CMSRP = 242.43	2	5	0	090
857-025CMSRP = 397.56	2-1/2	5	0	090
857-030CMSRP = 503.15	3	5	0	090
857-040CMSRP = 642.81	4	4	0	090

Union (Old Style) - Socket/EPDM
Socket x Socket with EPDM O-ring Seal
235 psi Maximum Internal Pressure Rating @ 73�F (23�C)

897-005CMSRP = 56.43	1/2	15	90	090
897-007CMSRP = 58.45	3/4	10	60	090
897-010CMSRP = 70.01	1	10	40	090
897-012CMSRP = 141.78	1-1/4	5	20	090
897-015CMSRP = 144.45	1-1/2	5	0	090
897-020CMSRP = 239.44	2	5	0	090
897-025CMSRP = 396.52	2-1/2	5	0	090
897-030CMSRP = 496.97	3	5	0	090
897-040CMSRP = 635.54	4	4	0	090

Union (Old Style) - Socket/Fipt/FKM
Socket x Fipt with FKM O-ring Seal
235 psi Maximum Internal Pressure Rating @ 73�F (23�C)

859-005CMSRP = 64.43	1/2	15	90	090
859-007CMSRP = 112.44	3/4	10	40	090
859-010CMSRP = 155.24	1	10	40	090
859-012CMSRP = 263.43	1-1/4	5	20	090
859-015CMSRP = 295.67	1-1/2	5	0	090
859-020CMSRP = 334.27	2	5	0	090
859-025CMSRP = 542.64	2-1/2	5	0	090
859-030CMSRP = 641.83	3	5	0	090
859-040CMSRP = 742.17	4	4	0	090

Union (Old Style) - Socket/Fipt/EPDM
Socket x Fipt with EPDM O-ring Seal
235 psi Maximum Internal Pressure Rating @ 73�F (23�C)

899-005CMSRP = 62.84	1/2	15	90	090
899-007CMSRP = 111.14	3/4	10	60	090
899-010CMSRP = 153.28	1	10	40	090
899-012CMSRP = 292.01	1-1/4	5	20	090

Made in the U.S.A.

Suitable for Oil-Free air handling to 25 psi, not for distribution of compressed air or gas

See Spears^® On-line Catalog @ www.spearsmfg.com for Pricing

Page 26

Schedule 80 CPVC Product
CPVC Schedule 80 Fittings

Print this Book

Unions

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

Union (Old Style) - Socket/Fipt/EPDM (continued)
Socket x Fipt with EPDM O-ring Seal

899-015CMSRP = 292.01	1-1/2	5	090
899-020CMSRP = 330.09	2	5	090
899-025CMSRP = 472.88	2-1/2	5	090
899-030CMSRP = 633.94	3	5	090
899-040CMSRP = 731.28	4	4	090

Union - Socket/Brass Fipt/FKM
Socket x Fipt with Brass Thread Insert & FKM O-ring Seal
235 psi Maximum Internal Pressure Rating @ 73�F (23�C)

859-005CBRMSRP = 211.80	1/2	10	60	096
859-007CBRMSRP = 302.21	3/4	10	20	096
859-010CBRMSRP = 336.61	1	10	0	096
859-012CBRMSRP = 564.27	1-1/4	5	0	096
859-015CBRMSRP = 641.25	1-1/2	5	0	096
859-020CBRMSRP = 724.75	2	5	0	096

Not intended to convey or dispense water for human consumption through drinking or cooking

Union - Socket/Brass Fipt/EPDM
Socket x Fipt with Brass Thread Insert & EPDM O-ring Seal
235 psi Maximum Internal Pressure Rating @ 73�F (23�C)

899-005CBRMSRP = 219.71	1/2	10	60	096
899-007CBRMSRP = 297.08	3/4	10	40	096
899-010CBRMSRP = 332.49	1	10	0	096
899-012CBRMSRP = 557.15	1-1/4	5	20	096
899-015CBRMSRP = 633.03	1-1/2	5	0	096
899-020CBRMSRP = 715.83	2	5	0	096

Not intended to convey or dispense water for human consumption through drinking or cooking

Union (Old Style) - Fipt/FKM
Fipt x Fipt with FKM O-ring Seal
235 psi Maximum Internal Pressure Rating @ 73�F (23�C)

858-005CMSRP = 60.61	1/2	15	90	090
858-007CMSRP = 107.16	3/4	10	60	090
858-010CMSRP = 147.78	1	10	40	090
858-012CMSRP = 281.57	1-1/4	5	20	090
858-015CMSRP = 281.57	1-1/2	5	0	090
858-020CMSRP = 318.29	2	5	0	090
858-025CMSRP = 512.75	2-1/2	5	0	090
858-030CMSRP = 972.97	3	5	0	090
858-040CMSRP = 1045.85	4	4	0	090

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

Union (Old Style) - Fipt/EPDM
Fipt x Fipt with EPDM O-ring Seal
235 psi Maximum Internal Pressure Rating @ 73�F (23�C)

898-005CMSRP = 59.87	1/2	15	90	090
898-007CMSRP = 105.86	3/4	10	60	090
898-010CMSRP = 145.97	1	10	40	090
898-012CMSRP = 278.33	1-1/4	5	20	090
898-015CMSRP = 278.33	1-1/2	5	0	090
898-020CMSRP = 314.40	2	5	0	090
898-025CMSRP = 442.94	2-1/2	5	0	090
898-030CMSRP = 881.25	3	5	0	090
898-040CMSRP = 1025.97	4	4	0	090

Union (Old Style) - Socket/Special Reinforced Fipt/FKM
Socket x SR Fipt w/FKM O-ring Seal - Stainless Steel Collar
235 psi Maximum Internal Pressure Rating @ 73�F (23�C)

859-002CSRMSRP = 52.49	1/4	25	150	096
859-003CSRMSRP = 52.49	3/8	25	100	096
859-005CSRMSRP = 33.36	1/2	10	60	096
859-007CSRMSRP = 58.85	3/4	10	60	096
859-010CSRMSRP = 81.06	1	10	40	096
859-012CSRMSRP = 154.54	1-1/4	5	20	096
859-015CSRMSRP = 168.00	1-1/2	5	0	096
859-020CSRMSRP = 174.87	2	5	0	096
859-030CSRMSRP = 491.99	3	5	0	096
859-040CSRMSRP = 573.99	4	4	0	096

Union (Old Style) - Socket/Special Reinforced Fipt/EPDM
Socket x SR Fipt w/EPDM O-ring Seal -Stainless Steel Collar
235 psi Maximum Internal Pressure Rating @ 73�F (23�C)

899-002CSRMSRP = 52.15	1/4	25	150	096
899-003CSRMSRP = 52.15	3/8	25	100	096
899-005CSRMSRP = 32.71	1/2	10	60	096
899-007CSRMSRP = 58.03	3/4	10	40	096
899-010CSRMSRP = 80.39	1	10	40	096
899-012CSRMSRP = 152.27	1-1/4	5	20	096
899-015CSRMSRP = 165.62	1-1/2	5	0	096
899-020CSRMSRP = 174.41	2	5	0	096
899-030CSRMSRP = 485.80	3	5	0	096
899-040CSRMSRP = 570.54	4	4	0	096

Page 27

Suitable for Oil-Free air handling to 25 psi, not for distribution of compressed air or gas

Spears^® Manufacturing Company

See Spears^® On-line Catalog @ www.spearsmfg.com for Pricing

Schedule 80 CPVC Product
Tank Adapters

Print this Book

Tank Adapters

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

Tank Adapters, CPVC New Style Standard with Neoprene Gaskets
Socket x Socket
150 psi Maximum Internal Pressure Rating @ 73�F (23�C)

8170-002CMSRP = 99.94	1/4	25	150	101
8170-003CMSRP = 99.94	3/8	25	150	101
8170-005CMSRP = 99.94	1/2	25	0	101
8170-007CMSRP = 118.88	3/4	25	0	101
8170-010CMSRP = 133.43	1	25	0	101
8170-012CMSRP = 170.19	1-1/4	20	0	101
8170-015CMSRP = 185.33	1-1/2	20	0	101
8170-020CMSRP = 261.62	2	15	0	101
8170-025CMSRP = 384.49	2-1/2	4	0	101
8170-030CMSRP = 457.67	3	4	0	101
8170-040CMSRP = 762.72	4	2	0	101
8170-060CMSRP = 2097.48	6	1	0	101
8170-080CMSRP = 4660.73	8	1	0	101

Tank Adapters, CPVC New Style Standard with EPDM Gaskets
Socket x Socket
150 psi Maximum Internal Pressure Rating @ 73�F (23�C)

8170E-002CMSRP = 113.66	1/4	25	150	101
8170E-003CMSRP = 113.66	3/8	25	150	101
8170E-005CMSRP = 113.66	1/2	25	0	101
8170E-007CMSRP = 127.58	3/4	25	0	101
8170E-010CMSRP = 148.13	1	25	0	101
8170E-012CMSRP = 187.46	1-1/4	20	0	101
8170E-015CMSRP = 196.71	1-1/2	20	0	101
8170E-020CMSRP = 283.57	2	15	0	101
8170E-025CMSRP = 402.78	2-1/2	4	0	101
8170E-030CMSRP = 479.57	3	4	0	101
8170E-040CMSRP = 796.02	4	2	0	101
8170E-060CMSRP = 2184.86	6	1	0	101
8170E-080CMSRP = 4796.97	8	1	0	101

Tank Adapters, CPVC New Style Standard with FKM Gaskets
Socket x Socket
150 psi Maximum Internal Pressure Rating @ 73�F (23�C)

8170V-002CMSRP = 149.01	1/4	25	150	101
8170V-003CMSRP = 149.01	3/8	25	150	101
8170V-005CMSRP = 149.01	1/2	25	0	101
8170V-007CMSRP = 171.45	3/4	25	0	101
8170V-010CMSRP = 198.45	1	25	0	101
8170V-012CMSRP = 243.85	1-1/4	20	0	101
8170V-015CMSRP = 254.20	1-1/2	20	0	101
8170V-020CMSRP = 384.84	2	15	0	101
8170V-025CMSRP = 553.89	2-1/2	4	0	101

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

Tank Adapters, CPVC New Style Standard with FKM Gaskets (continued)
Socket x Socket

8170V-030CMSRP = 659.44	3	4	101
8170V-040CMSRP = 1460.61	4	2	101
8170V-060CMSRP = 3670.69	6	1	101
8170V-080CMSRP = 8586.72	8	1	101

Tank Adapters, CPVC New Style Standard with Neoprene Gaskets
Socket x Fipt
150 psi Maximum Internal Pressure Rating @ 73�F (23�C)

8171-002CMSRP = 99.94	1/4	25	150	101
8171-003CMSRP = 99.94	3/8	25	200	101
8171-005CMSRP = 99.94	1/2	25	0	101
8171-007CMSRP = 118.88	3/4	25	0	101
8171-010CMSRP = 133.43	1	25	0	101
8171-012CMSRP = 170.19	1-1/4	20	0	101
8171-015CMSRP = 185.33	1-1/2	20	0	101
8171-020CMSRP = 261.62	2	15	0	101
8171-025CMSRP = 384.49	2-1/2	4	0	101
8171-030CMSRP = 457.67	3	4	0	101
8171-040CMSRP = 762.72	4	2	0	101
8171-060CMSRP = 2097.48	6	1	0	101

Tank Adapters, CPVC New Style Standard with EPDM Gaskets
Socket x Fipt
150 psi Maximum Internal Pressure Rating @ 73�F (23�C)

8171E-002CMSRP = 113.66	1/4	25	150	101
8171E-003CMSRP = 113.66	3/8	25	200	101
8171E-005CMSRP = 113.66	1/2	25	0	101
8171E-007CMSRP = 127.58	3/4	25	0	101
8171E-010CMSRP = 148.13	1	25	0	101
8171E-012CMSRP = 187.46	1-1/4	20	0	101
8171E-015CMSRP = 196.71	1-1/2	20	0	101
8171E-020CMSRP = 283.57	2	15	0	101
8171E-025CMSRP = 402.78	2-1/2	4	0	101
8171E-030CMSRP = 479.57	3	4	0	101
8171E-040CMSRP = 796.02	4	2	0	101
8171E-060CMSRP = 2184.84	6	1	0	101

Tank Adapters, CPVC New Style Standard with FKM Gaskets
Socket x Fipt
150 psi Maximum Internal Pressure Rating @ 73�F (23�C)

8171V-002CMSRP = 149.01	1/4	25	150	101
8171V-003CMSRP = 149.01	3/8	25	200	101
8171V-005CMSRP = 149.01	1/2	25	0	101
8171V-007CMSRP = 171.45	3/4	25	0	101
8171V-010CMSRP = 198.45	1	25	0	101
8171V-012CMSRP = 243.85	1-1/4	20	0	101

Made in the U.S.A.

Suitable for Oil-Free air handling to 25 psi, not for distribution of compressed air or gas

See Spears^® On-line Catalog @ www.spearsmfg.com for Pricing

Page 28

Schedule 80 CPVC Product
Tank Adapters

Print this Book

Tank Adapters

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

Tank Adapters, CPVC New Style Standard with FKM Gaskets (continued)
Socket x Fipt

8171V-015CMSRP = 254.20	1-1/2	20	101
8171V-020CMSRP = 384.84	2	15	101
8171V-025CMSRP = 553.98	2-1/2	4	101
8171V-030CMSRP = 659.44	3	4	101
8171V-040CMSRP = 1460.61	4	2	101
8171V-060CMSRP = 3670.69	6	1	101

Tank Adapters, CPVC New Style Special Reinforced (SR) Threaded with Neoprene Gaskets
Socket x SR Fipt - Stainless Steel Collar
150 psi Maximum Internal Pressure Rating @ 73�F (23�C)

8171-002CSRMSRP = 102.97	1/4	25	150	101
8171-003CSRMSRP = 102.97	3/8	25	200	101
8171-005CSRMSRP = 102.97	1/2	25	0	101
8171-007CSRMSRP = 123.24	3/4	25	0	101
8171-010CSRMSRP = 139.41	1	25	0	101
8171-012CSRMSRP = 179.85	1-1/4	20	0	101
8171-015CSRMSRP = 201.88	1-1/2	20	0	101
8171-020CSRMSRP = 279.17	2	15	0	101
8171-025CSRMSRP = 424.71	2-1/2	4	0	101
8171-030CSRMSRP = 505.48	3	4	0	101
8171-040CSRMSRP = 812.36	4	2	0	101
8171-060CSRMSRP = 2145.52	6	1	0	101

Tank Adapters, CPVC New Style Special Reinforced (SR) Threaded with EPDM Gaskets
Socket x SR Fipt - Stainless Steel Collar
150 psi Maximum Internal Pressure Rating @ 73�F (23�C)

8171E-002CSRMSRP = 116.71	1/4	25	150	101
8171E-003CSRMSRP = 116.71	3/8	25	200	101
8171E-005CSRMSRP = 116.71	1/2	25	0	101
8171E-007CSRMSRP = 131.89	3/4	25	0	101
8171E-010CSRMSRP = 157.71	1	25	0	101
8171E-012CSRMSRP = 197.09	1-1/4	20	0	101
8171E-015CSRMSRP = 213.23	1-1/2	20	0	101
8171E-020CSRMSRP = 301.46	2	15	0	101
8171E-025CSRMSRP = 442.97	2-1/2	4	0	101
8171E-030CSRMSRP = 527.35	3	4	0	101
8171E-040CSRMSRP = 845.54	4	2	0	101
8171E-060CSRMSRP = 2232.95	6	2	0	101

Tank Adapters, CPVC New Style Special Reinforced (SR) Threaded with FKM Gaskets
Socket x SR Fipt - Stainless Steel Collar
150 psi Maximum Internal Pressure Rating @ 73�F (23�C)

8171V-002CSRMSRP = 152.03	1/4	25	150	101
8171V-003CSRMSRP = 152.03	3/8	25	200	101

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

Tank Adapters, CPVC New Style Special Reinforced (SR) Threaded with FKM Gaskets (continued)
Socket x SR Fipt - Stainless Steel Collar

8171V-005CSRMSRP = 152.03	1/2	25	101
8171V-007CSRMSRP = 175.77	3/4	25	101
8171V-010CSRMSRP = 204.48	1	25	101
8171V-012CSRMSRP = 253.48	1-1/4	20	101
8171V-015CSRMSRP = 270.67	1-1/2	20	101
8171V-020CSRMSRP = 403.07	2	15	101
8171V-025CSRMSRP = 593.94	2-1/2	4	101
8171V-030CSRMSRP = 707.26	3	4	101
8171V-040CSRMSRP = 1510.13	4	2	101
8171V-060CSRMSRP = 3728.48	6	2	101

Tank Adapters, CPVC New Style Standard with Neoprene Gaskets
Fipt x Fipt
150 psi Maximum Internal Pressure Rating @ 73�F (23�C)

8172-002CMSRP = 133.43	1/4	25	150	101
8172-003CMSRP = 133.43	3/8	25	200	101
8172-005CMSRP = 133.43	1/2	25	0	101
8172-007CMSRP = 154.06	3/4	25	0	101
8172-010CMSRP = 168.53	1	25	0	101
8172-012CMSRP = 237.94	1-1/4	20	0	101
8172-015CMSRP = 260.09	1-1/2	20	0	101
8172-020CMSRP = 324.15	2	15	0	101
8172-025CMSRP = 456.18	2-1/2	4	0	101
8172-030CMSRP = 543.03	3	4	0	101
8172-040CMSRP = 857.99	4	2	0	101
8172-060CMSRP = 2383.48	6	1	0	101

Tank Adapters, CPVC New Style Standard with EPDM Gaskets
Fipt x Fipt
150 psi Maximum Internal Pressure Rating @ 73�F (23�C)

8172E-002CMSRP = 138.67	1/4	25	150	101
8172E-003CMSRP = 138.67	3/8	25	200	101
8172E-005CMSRP = 138.67	1/2	25	0	101
8172E-007CMSRP = 163.49	3/4	25	0	101
8172E-010CMSRP = 176.19	1	25	0	101
8172E-012CMSRP = 247.51	1-1/4	20	0	101
8172E-015CMSRP = 282.48	1-1/2	20	0	101
8172E-020CMSRP = 349.09	2	15	0	101
8172E-025CMSRP = 513.24	2-1/2	4	0	101
8172E-030CMSRP = 611.05	3	4	0	101
8172E-040CMSRP = 1017.35	4	2	0	101
8172E-060CMSRP = 2419.47	6	1	0	101

Page 29

Suitable for Oil-Free air handling to 25 psi, not for distribution of compressed air or gas

Spears^® Manufacturing Company

See Spears^® On-line Catalog @ www.spearsmfg.com for Pricing

Schedule 80 CPVC Product
Tank Adapters

Print this Book

Tank Adapters

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

Tank Adapters, CPVC New Style Standard with FKM Gaskets
Fipt x Fipt
150 psi Maximum Internal Pressure Rating @ 73�F (23�C)

8172V-002CMSRP = 214.60	1/4	25	150	101
8172V-003CMSRP = 214.60	3/8	25	200	101
8172V-005CMSRP = 214.60	1/2	25	0	101
8172V-007CMSRP = 241.89	3/4	25	0	101
8172V-010CMSRP = 278.36	1	25	0	101
8172V-012CMSRP = 341.45	1-1/4	20	0	101
8172V-015CMSRP = 353.29	1-1/2	20	0	101
8172V-020CMSRP = 550.38	2	15	0	101
8172V-025CMSRP = 781.04	2-1/2	4	0	101
8172V-030CMSRP = 929.68	3	4	0	101
8172V-040CMSRP = 2444.94	4	2	0	101
8172V-060CMSRP = 4481.22	6	1	0	101

Tank Adapters, CPVC New Style Special Reinforced (SR) Threaded with Neoprene Gaskets
Fipt x SR Fipt - Stainless Steel Collar
150 psi Maximum Internal Pressure Rating @ 73�F (23�C)

8172-002CSRMSRP = 136.40	1/4	25	150	101
8172-003CSRMSRP = 136.40	3/8	25	200	101
8172-005CSRMSRP = 136.40	1/2	25	0	101
8172-007CSRMSRP = 158.40	3/4	25	0	101
8172-010CSRMSRP = 174.53	1	25	0	101
8172-012CSRMSRP = 247.58	1-1/4	20	0	101
8172-015CSRMSRP = 276.60	1-1/2	20	0	101
8172-020CSRMSRP = 342.00	2	15	0	101
8172-025CSRMSRP = 496.35	2-1/2	4	0	101
8172-030CSRMSRP = 590.92	3	4	0	101
8172-040CSRMSRP = 907.58	4	2	0	101
8172-060CSRMSRP = 2431.54	6	2	0	101

Tank Adapters, CPVC New Style Special Reinforced (SR) Threaded with EPDM Gaskets
Fipt x SR Fipt - Stainless Steel Collar
150 psi Maximum Internal Pressure Rating @ 73�F (23�C)

8172E-002CSRMSRP = 141.75	1/4	25	150	101
8172E-003CSRMSRP = 141.75	3/8	25	200	101
8172E-005CSRMSRP = 141.75	1/2	25	0	101
8172E-007CSRMSRP = 167.81	3/4	25	0	101
8172E-010CSRMSRP = 182.20	1	25	0	101
8172E-012CSRMSRP = 257.18	1-1/4	20	0	101
8172E-015CSRMSRP = 298.99	1-1/2	20	0	101
8172E-020CSRMSRP = 366.97	2	15	0	101
8172E-025CSRMSRP = 553.60	2-1/2	4	0	101
8172E-030CSRMSRP = 659.05	3	4	0	101
8172E-040CSRMSRP = 1066.92	4	2	0	101

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

Tank Adapters, CPVC New Style Special Reinforced (SR) Threaded with EPDM Gaskets (continued)
Fipt x SR Fipt - Stainless Steel Collar

8172E-060CSRMSRP = 2467.49

101

Tank Adapters, CPVC New Style Special Reinforced (SR) Threaded with FKM Gaskets
Fipt x SR Fipt - Stainless Steel Collar
150 psi Maximum Internal Pressure Rating @ 73�F (23�C)

8172V-002CSRMSRP = 217.64	1/4	25	150	101
8172V-003CSRMSRP = 217.64	3/8	25	200	101
8172V-005CSRMSRP = 217.64	1/2	25	0	101
8172V-007CSRMSRP = 246.22	3/4	25	0	101
8172V-010CSRMSRP = 284.38	1	25	0	101
8172V-012CSRMSRP = 351.09	1-1/4	20	0	101
8172V-015CSRMSRP = 369.77	1-1/2	20	0	101
8172V-020CSRMSRP = 568.28	2	15	0	101
8172V-025CSRMSRP = 821.15	2-1/2	4	0	101
8172V-030CSRMSRP = 977.56	3	4	0	101
8172V-040CSRMSRP = 2494.51	4	2	0	101
8172V-060CSRMSRP = 4529.35	6	2	0	101

Tank Adapter, CPVC Self Aligning with Neoprene Gasket
Fipt
75 psi Maximum Internal Pressure Rating @ 73�F (23�C)

8172SA-010CMSRP = 436.92	1	5	101
8172SA-020CMSRP = 659.44	2	4	101
8172SA-030CMSRP = 1027.55	3	2	101

Tank Adapter, CPVC Self Aligning with EPDM Gasket
Fipt
75 psi Maximum Internal Pressure Rating @ 73�F (23�C)

8172ESA-010CMSRP = 459.36	1	5	101
8172ESA-020CMSRP = 695.62	2	4	101
8172ESA-030CMSRP = 1081.94	3	2	101

Tank Adapter, CPVC Self Aligning with FKM Gasket
Fipt
75 psi Maximum Internal Pressure Rating @ 73�F (23�C)

8172VSA-010CMSRP = 907.87	1	5	101
8172VSA-020CMSRP = 1374.22	2	4	101
8172VSA-030CMSRP = 2135.15	3	2	101

Made in the U.S.A.

Suitable for Oil-Free air handling to 25 psi, not for distribution of compressed air or gas

See Spears^® On-line Catalog @ www.spearsmfg.com for Pricing

Page 30

Schedule 80 CPVC Product
Tank Adapters

Print this Book

Tank Adapters

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

Tank Adapter, CPVC Old Style with Neoprene Gasket
Socket x Fipt
150 psi Maximum Internal Pressure Rating @ 73�F (23�C)

871-005CMSRP = 99.94	1/2	25	101
871-007CMSRP = 118.88	3/4	25	101
871-010CMSRP = 133.43	1	25	101
871-012CMSRP = 170.19	1-1/4	20	101
871-015CMSRP = 185.33	1-1/2	20	101
871-020CMSRP = 261.62	2	15	101
871-030CMSRP = 457.67	3	4	101
871-040CMSRP = 762.72	4	2	101

Tank Adapter, CPVC Old Style with Neoprene Gasket
Fipt x Fipt
150 psi Maximum Internal Pressure Rating @ 73�F (23�C)

872-005CMSRP = 133.43	1/2	25	101
872-007CMSRP = 154.06	3/4	25	101
872-010CMSRP = 168.53	1	25	101
872-012CMSRP = 237.94	1-1/4	20	101
872-015CMSRP = 260.09	1-1/2	20	101
872-020CMSRP = 324.15	2	15	101
872-030CMSRP = 543.03	3	4	101
872-040CMSRP = 857.99	4	2	101

Tank Adapter Gasket Only - Neoprene (New Style)

3N-002MSRP = 5.61	1/4	100	299
3N-003MSRP = 5.61	3/8	50	299
3N-005MSRP = 5.61	1/2	10	299
3N-007MSRP = 6.02	3/4	10	299
3N-010MSRP = 6.39	1	10	299
3N-012MSRP = 8.84	1-1/4	10	299
3N-015MSRP = 10.35	1-1/2	10	299
3N-020MSRP = 13.56	2	10	299
3N-025MSRP = 14.14	2-1/2	10	299
3N-030MSRP = 14.78	3	10	299
3N-040MSRP = 40.83	4	50	299
2N-060MSRP = 51.01	6	10	299
3N-080MSRP = 233.94	8	10	299

Tank Adapter Gasket Only - EPDM (New Style)

3E-002MSRP = 3.46	1/4	10	0	299
3E-003MSRP = 3.97	3/8	10	0	299

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

Tank Adapter Gasket Only - EPDM (New Style) (continued)

3E-005MSRP = 5.34	1/2	10	299
3E-007MSRP = 5.64	3/4	10	299
3E-010MSRP = 8.12	1	10	299
3E-012MSRP = 17.07	1-1/4	10	299
3E-015MSRP = 17.54	1-1/2	10	299
3E-020MSRP = 20.09	2	10	299
3E-025MSRP = 28.44	2-1/2	10	299
3E-030MSRP = 30.61	3	10	299
3E-040MSRP = 46.07	4	10	299
2E-060MSRP = 83.19	6	10	299
3E-080MSRP = 219.86	8	10	299

Tank Adapter Gasket Only - FKM (New Style)

3V-002MSRP = 21.23	1/4	10	299
3V-003MSRP = 26.98	3/8	10	299
3V-005MSRP = 34.35	1/2	10	299
3V-007MSRP = 38.07	3/4	10	299
3V-010MSRP = 41.59	1	10	299
3V-012MSRP = 77.83	1-1/4	10	299
3V-015MSRP = 83.55	1-1/2	10	299
3V-020MSRP = 107.64	2	10	299
3V-025MSRP = 131.16	2-1/2	10	299
3V-030MSRP = 236.54	3	10	299
3V-040MSRP = 294.61	4	10	299
2V-060MSRP = 1039.93	6	10	299
3V-080MSRP = 1673.66	8	10	299

Tank Adapter Gasket Only - Neoprene (Old Style)

2N-005MSRP = 5.61	1/2	10	299
2N-007MSRP = 6.02	3/4	10	299
2N-010MSRP = 6.39	1	10	299
2N-015MSRP = 10.35	1-1/4 OR 1-1/2	10	299
2N-020MSRP = 13.56	2	10	299
2N-030MSRP = 14.78	3	10	299
2N-040MSRP = 40.83	4	10	299

Tank Adapter Gasket Only - EPDM (Old Style)

2E-005MSRP = 6.49	1/2	10	299
2E-007MSRP = 6.73	3/4	10	299
2E-010MSRP = 11.66	1	10	299
2E-015MSRP = 17.54	1-1/4 OR 1-1/2	10	299
2E-020MSRP = 20.09	2	10	299
2E-030MSRP = 30.61	3	10	299
2E-040MSRP = 46.07	4	10	299

Page 31

Suitable for Oil-Free air handling to 25 psi, not for distribution of compressed air or gas

Spears^® Manufacturing Company

See Spears^® On-line Catalog @ www.spearsmfg.com for Pricing

Schedule 80 CPVC Product
Tank Adapters & Pipe Flanges

Print this Book

Tank Adapters

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

Tank Adapter Wrench Sets (New Style)
Body Wrench & Nut Wrench

TAW-002MSRP = 45.25	1/4	1	25	299
TAW-003MSRP = 45.25	3/8	1	25	299
TAW-005MSRP = 45.25	1/2	1	25	299
TAW-007MSRP = 46.14	3/4	1	25	299
TAW-010MSRP = 47.99	1	1	25	299
TAW-012MSRP = 54.14	1-1/4	1	20	299
TAW-015MSRP = 58.71	1-1/2	1	20	299
TAW-020MSRP = 66.88	2	1	10	299
TAW-025MSRP = 73.99	2-1/2	1	10	299
TAW-030MSRP = 81.56	3	1	10	299
TAW-040MSRP = 87.36	4	1	10	299

Tank Adapter Individual Body Wrench (New Style)

TAW1-002MSRP = 25.40	1/4	500	299
TAW1-003MSRP = 25.40	3/8	400	299
TAW1-005MSRP = 25.40	1/2	250	299
TAW1-007MSRP = 25.88	3/4	220	299
TAW1-010MSRP = 26.95	1	200	299
TAW1-012MSRP = 30.52	1-1/4	300	299
TAW1-015MSRP = 32.87	1-1/2	150	299
TAW1-020MSRP = 35.69	2	100	299
TAW1-025MSRP = 37.29	2-1/2	80	299
TAW1-030MSRP = 46.76	3	74	299
TAW1-040MSRP = 48.11	4	35	299

Tank Adapter Individual Nut Wrench (New Style)

TAW2-002MSRP = 25.40	1/4	300	299
TAW2-003MSRP = 25.40	3/8	250	299
TAW2-005MSRP = 25.40	1/2	200	299
TAW2-007MSRP = 25.88	3/4	160	299
TAW2-010MSRP = 26.95	1	110	299
TAW2-012MSRP = 30.52	1-1/4	200	299
TAW2-015MSRP = 32.87	1-1/2	120	299
TAW2-020MSRP = 35.69	2	100	299
TAW2-025MSRP = 37.29	2-1/2	50	299
TAW2-030MSRP = 46.76	3	40	299
TAW2-040MSRP = 48.11	4	35	299

Pipe Flanges

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

Flange One Piece
Socket
150 psi Maximum Internal Pressure Rating @ 73�F (23�C)

851-005CMSRP = 92.61	1/2	25	090
851-007CMSRP = 94.76	3/4	25	090
851-010CMSRP = 103.43	1	15	090
851-012CMSRP = 126.28	1-1/4	15	090
851-015CMSRP = 140.15	1-1/2	20	090
851-020CMSRP = 170.60	2	10	090
851-025CMSRP = 351.54	2-1/2	10	090
851-030CMSRP = 367.58	3	10	090
851-040CMSRP = 496.65	4	5	090
851-050CMSRP = 910.18	5	5	090
851-060CMSRP = 910.18	6	5	090
851-080CMSRP = 2539.52	8	2	090
851-100CMSRP = 3169.07	10	2	091
851-120CMSRP = 4451.49	12	2	091

Flange One Piece
Fipt
150 psi Maximum Internal Pressure Rating @ 73�F (23�C)

852-005CMSRP = 129.49	1/2	25	0	090
852-007CMSRP = 156.98	3/4	25	0	090
852-010CMSRP = 172.11	1	15	0	090
852-012CMSRP = 237.72	1-1/4	15	0	090
852-015CMSRP = 251.67	1-1/2	20	0	090
852-020CMSRP = 256.32	2	10	0	090
852-025CMSRP = 416.01	2-1/2	10	0	090
852-030CMSRP = 412.80	3	10	0	090
852-040CMSRP = 641.69	4	5	0	090
852-060CFMSRP = 958.77	6	1	8	097
852-080CFMSRP = 2374.88	8	1	2	097

Flange - Special Reinforced One Piece Threaded
SR Fipt - Stainless Steel Collar
150 psi Maximum Internal Pressure Rating @ 73�F (23�C)

852-005CSRMSRP = 71.15	1/2	25	096
852-007CSRMSRP = 86.34	3/4	25	096
852-010CSRMSRP = 94.44	1	15	096
852-012CSRMSRP = 130.73	1-1/4	15	096
852-015CSRMSRP = 138.61	1-1/2	15	096
852-020CSRMSRP = 141.96	2	10	096
852-025CSRMSRP = 228.35	2-1/2	10	096
852-030CSRMSRP = 226.59	3	10	096
852-040CSRMSRP = 424.64	4	5	096

Made in the U.S.A.

Suitable for Oil-Free air handling to 25 psi, not for distribution of compressed air or gas

See Spears^® On-line Catalog @ www.spearsmfg.com for Pricing

Page 32

Schedule 80 CPVC Product
Pipe Flanges

Print this Book

Pipe Flanges

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

Flange - Blind

1/2" - 12" Molded - 150 psi Maximum Internal Pressure Rating @ 73�F (23�C) 14" - 24" Fabricated - 50 psi Maximum Internal Pressure Rating @ 73�F (23�C)

853-005CMSRP = 83.27	1/2	25	100	090
853-007CMSRP = 90.29	3/4	25	0	090
853-010CMSRP = 112.57	1	20	0	090
853-012CMSRP = 127.35	1-1/4	20	0	090
853-015CMSRP = 178.25	1-1/2	15	0	090
853-020CMSRP = 187.27	2	10	0	090
853-025CMSRP = 283.28	2-1/2	10	0	090
853-030CMSRP = 352.21	3	10	0	090
853-040CMSRP = 477.03	4	8	0	090
853-060CMSRP = 800.22	6	5	0	090
853-080CMSRP = 1484.29	8	5	0	090
853-100CMSRP = 2676.32	10	3	0	091
853-120CMSRP = 4496.20	12	2	0	091
853-140CFMSRP = 5225.17	14	1	0	097
853-160CFMSRP = 8101.61	16	1	0	097
853-180CFMSRP = 9987.20	18	1	0	097
853-200CFMSRP = 10701.60	20	1	0	097
853-240CFMSRP = 13021.66	24	1	0	097

Flange Van Stone Style with Plastic Ring
Socket
1/2" - 18" molded - 150 psi = maximum internal pressure rating @ 73�F (23�C) 18" - 24" fabricated - 50 psi = maximum internal pressure rating @ 73�F (23�C)

854-005CMSRP = 55.93	1/2	25	090
854-007CMSRP = 57.20	3/4	25	090
854-010CMSRP = 62.43	1	15	090
854-012CMSRP = 76.23	1-1/4	15	090
854-015CMSRP = 84.69	1-1/2	20	090
854-020CMSRP = 102.52	2	10	090
854-025CMSRP = 212.42	2-1/2	10	090
854-030CMSRP = 222.40	3	10	090
854-040CMSRP = 300.35	4	5	090
854-050CMSRP = 511.76	5	5	090
854-060CMSRP = 511.76	6	5	090
854-080CMSRP = 1539.87	8	2	090
854-100CMSRP = 3706.95	10	2	091
854-120CMSRP = 5562.42	12	2	091
854-140CMSRP = 6267.92	14	1	095
854-160CMSRP = 7834.93	16	1	095
854-180CMSRP = 12719.09	18	1	095

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

Flange Van Stone Style with Plastic Ring (continued)
Socket

854-180CFPMSRP = 14181.20	18	1	097
854-200CFPMSRP = 12598.69	20	1	097
854-240CFPMSRP = 16242.21	24	1	097

Flange Van Stone Style with Plastic Ring
Spigot
150 psi Maximum Internal Pressure Rating @ 73�F (23�C)

856-005CMSRP = 64.66	1/2	25	090
856-007CMSRP = 69.44	3/4	25	090
856-010CMSRP = 78.82	1	15	090
856-012CMSRP = 97.55	1-1/4	15	090
856-015CMSRP = 107.87	1-1/2	15	090
856-020CMSRP = 150.98	2	10	090
856-025CMSRP = 236.49	2-1/2	10	090
856-030CMSRP = 258.95	3	10	090
856-040CMSRP = 266.49	4	5	090
856-060CMSRP = 581.82	6	4	090
856-080CMSRP = 1185.99	8	2	090
856-100CMSRP = 3982.48	10	2	091
856-120CMSRP = 5982.28	12	2	091
856-140CFPMSRP = 6365.17	14	1	097
856-160CFPMSRP = 7884.74	16	1	097
856-180CFPMSRP = 7810.42	18	1	097
856-200CFPMSRP = 9308.59	20	1	097
856-240CFPMSRP = 16488.35	24	1	097

Flange Van Stone Style with Plastic Solid Ring
Socket
150 psi Maximum Internal Pressure Rating @ 73�F (23�C)

S854-030CMSRP = 317.66	3	10	090
S854-040CMSRP = 429.15	4	5	090
S854-060CMSRP = 731.06	6	4	090
S854-080CMSRP = 2199.71	8	2	090
S854-100CMSRP = 5295.68	10	2	091
S854-120CMSRP = 7946.33	12	2	091

Flange Van Stone Style Class�300 Bolt Pattern Fabricated with Plastic Ring
Socket
Molded with fabricated ring - 150 psi = maximum internal pressure rating @ 73�F (23�C)

854-005CL300CMSRP = 425.59	1/2	25	097
854-007CL300CMSRP = 570.22	3/4	25	097
854-010CL300CMSRP = 695.29	1	15	097
854-012CL300CMSRP = 738.66	1-1/4	15	097
854-015CL300CMSRP = 766.99	1-1/2	20	097
854-020CL300CMSRP = 852.03	2	10	097
854-025CL300CMSRP = 1013.86	2-1/2	10	097

Page 33

Suitable for Oil-Free air handling to 25 psi, not for distribution of compressed air or gas

Spears^® Manufacturing Company

See Spears^® On-line Catalog @ www.spearsmfg.com for Pricing

Schedule 80 CPVC Product
Pipe Flanges & Van Stone Style Flange Replacement Split Rings

Print this Book

Pipe Flanges

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

Flange Van Stone Style Class�300 Bolt Pattern Fabricated with Plastic Ring (continued)
Socket

854-030CL300CMSRP = 1297.13	3	10	097
854-040CL300CMSRP = 1737.61	4	5	097
854-060CL300CMSRP = 3281.23	6	4	097
854-080CL300CMSRP = 3775.65	8	3	097
854-100CL300CMSRP = 4268.93	10	2	097
854-120CL300CMSRP = 5333.19	12	2	097
854-140CL300CMSRP = 5923.23	14	1	097
854-160CL300CMSRP = 6232.44	16	1	097

Flange Van Stone Style with Plastic Ring
Fipt
150 psi Maximum Internal Pressure Rating @ 73�F (23�C)

855-005CMSRP = 78.20	1/2	25	0	090
855-007CMSRP = 94.77	3/4	25	0	090
855-010CMSRP = 103.45	1	15	0	090
855-012CMSRP = 142.44	1-1/4	15	0	090
855-015CMSRP = 152.06	1-1/2	20	0	090
855-020CMSRP = 154.93	2	10	0	090
855-025CMSRP = 249.39	2-1/2	10	0	090
855-030CMSRP = 249.39	3	10	0	090
855-040CMSRP = 419.37	4	5	0	090
855-060C1MSRP = 656.43	6	1	0	090
855-060CFMSRP = 583.56	6	1	2	097
855-080C1MSRP = 1008.95	8	2	0	090
855-080CFMSRP = 896.84	8	1	2	097
855-100CFMSRP = 1521.94	10	1	2	097
855-120CFMSRP = 1926.71	12	1	0	097

¹ Flange assembled with molded Female Adapter

Flange Van Stone Style with Steel Ring
Socket
150 psi Maximum Internal Pressure Rating @73�F (23�C)

854-120CFSMSRP = 1804.46	12	1	097
854-140CFSMSRP = 2717.88	14	1	098
854-160CFSMSRP = 3825.23	16	1	097
854-180CFSMSRP = 4446.80	18	1	097
854-200CFSMSRP = 5231.83	20	1	097
854-240CFSMSRP = 8466.56	24	1	097

Flange One Piece Multi-Bolt Pattern*
ASTM Socket x Multi-bolt Pattern Ring
150 psi Maximum Internal Pressure Rating @ 73�F (23�C)

M851-100CMSRP = 1787.65	10	2	0	091
M851-120CMSRP = 2755.16	12	2	0	091

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

Flange One Piece Multi-Bolt Pattern* (continued)
ASTM Socket x Multi-bolt Pattern Ring

Hubs fit 10" and 12" ASTM IPS pipe. Rings are manufactured to accept bolt patterns in size 10" and 12" in ANSI Class 150, B.S. 4504 PN10, B.S. 4504 PN16, B.S. 10 Table E for size 10". Consult Spears^� Manufacturing Company Technical Services for additional information. Not for use with wafer valves.

Flange Van Stone Style with Plastic Ring ASTM
Socket x Multi-bolt Pattern Ring
150 psi Maximum Internal Pressure Rating @ 73�F (23�C)

M854-020CMSRP = 102.52	2	10	090
M854-060CMSRP = 511.76	6	4	090
M854-080CMSRP = 1539.87	8	2	090

Flange Van Stone Style with PN 10/16 Drilling CPVC Ring
ASTM Socket x DIN PN 10/16 Drilling
150 psi Maximum Internal Pressure Rating @ 73�F (23�C)

854-030CDINMSRP = 222.40	3	10	0	090
854-040CDINMSRP = 300.35	4	5	0	090

* Hubs fit 3� or 4� ASTM IPS Pipe. Rings are manufactured to
DIN 8063-4 PN 10 and PN 16 bolt patterns.

Van Stone Style Flange Replacement Split Rings

Application & Use of Van Stone Style Flange Replacement Split Rings

Designed for easy Van Stone style flange ring replacement in the event of system modification, repair, or improper assembly without having to remove existing flange hub. Split rings are made as a direct replacement of existing one-piece rings used on Spears® brand only of Van Stone style flanges with ANSI Class 150 bolt pattern plastic rings. Remove old ring to be replaced then simply place the split ring sections around hub and install flange bolts (not included) through special designed section overlap to hold in position. Install appropriate user supplied bolts, washers and gasket (see Flange Gasket and Bolt Hardware Kits in this catalog); torque to specifications according to normal flange assembly. Split rings are a set of either 2-pieces or 4-pieces (illustrated) sections depending on size, in regular PVC, Glass Filled PVC, or CPVC for flange type and sizes listed.

Flange Replacement Split Rings, CPVC
For Spears^� Flanges with CPVC Rings

854-005-1SCMSRP = 162.40	1/2	25	0	090
854-007-1SCMSRP = 172.40	3/4	25	0	090

Made in the U.S.A.

Suitable for Oil-Free air handling to 25 psi, not for distribution of compressed air or gas

See Spears^® On-line Catalog @ www.spearsmfg.com for Pricing

Page 34

Schedule 80 CPVC Product
Van Stone Style Flange Replacement Split Rings & Flange Insulating Joints & Flange Bolt Kits

Print this Book

Van Stone Style Flange Replacement Split Rings

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

Flange Replacement Split Rings, CPVC (continued)
For Spears^� Flanges with CPVC Rings

854-010-1SCMSRP = 192.82	1	10	0	090
854-012-1SCMSRP = 196.56	1-1/4	15	0	090
854-015-1SCMSRP = 201.40	1-1/2	20	0	090
854-020-1SCMSRP = 267.28	2	1	40	090
854-025-1SCMSRP = 309.18	2-1/2	10	0	090
854-030-1SCMSRP = 342.83	3	10	0	090
854-040-1SCMSRP = 363.05	4	10	0	090
854-050-1SCMSRP = 497.76	5	10	0	090
854-060-1SCMSRP = 588.96	6	5	0	090
854-080-1SCMSRP = 672.92	8	4	0	090
854-100-1SCMSRP = 849.44	10	4	0	091
854-120-1SCMSRP = 1052.80	12	2	0	091
854-140-1SCMSRP = 1442.06	14	2	0	091
854-160-1SCMSRP = 1791.43	16	1	0	095
854-180-1SCMSRP = 1945.72	18	1	0	095
854-200-1SCMSRP = 12403.99	20	1	0	097
854-240-1SCMSRP = 12652.88	24	1	0	097

Fits 854-xxxC Socket, 855-xxxC Threaded, and 856-xxxC Spigot hub configurations

Flange Insulating Joints

Flange Insulating Joints - Class 150 Bolt Pattern
PP Flange Spacer with PVC Bolt Isolators
Size = Nominal Flange Diameter x Thickness (in.) For Dielectric Insulation Between Dissimilar Metal Flanges 300 psi Maximum Internal Pressure Rating @ 73�F (23�C)

IJ-030-010PMSRP = 952.57	3X1	1	016
IJ-040-010PMSRP = 1064.32	4X1	1	016
IJ-060-010PMSRP = 1265.05	6X1	1	016
IJ-080-010PMSRP = 1468.18	8X1	1	016
IJ-100-010PMSRP = 2984.07	10X1	1	016
IJ-120-010PMSRP = 3232.06	12X1	1	016
IJ-140-010PMSRP = 4188.00	14X1	1	016
IJ-160-010PMSRP = 5321.77	16X1	1	016
IJ-180-010PMSRP = 7123.65	18X1	1	016
IJ-200-010PMSRP = 9196.51	20X1	1	016
IJ-240-010PMSRP = 12772.24	24X1	1	016

Flange Insulating Joints - Class 300 Bolt Pattern
PP Flange Spacer with PVC Bolt Isolators
Size = Nominal Flange Diameter x Thickness (in.) For Dielectric Insulation Between Dissimilar Metal Flanges 300 psi Maximum Internal Pressure Rating @ 73�F (23�C)

IJ300-030-010PMSRP = 1403.26

3X1

016

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

Flange Insulating Joints - Class 300 Bolt Pattern (continued)
PP Flange Spacer with PVC Bolt Isolators

IJ300-040-010PMSRP = 1560.76	4X1	1	016
IJ300-060-010PMSRP = 2390.61	6X1	1	016
IJ300-080-010PMSRP = 2982.38	8X1	1	016
IJ300-100-010PMSRP = 4947.62	10X1	1	016
IJ300-120-010PMSRP = 6501.73	12X1	1	016
IJ300-140-010PMSRP = 8190.59	14X1	1	016
IJ300-160-010PMSRP = 8733.80	16X1	1	016
IJ300-180-010PMSRP = 10915.19	18X1	1	016
IJ300-200-010PMSRP = 12646.18	20X1	1	016
IJ300-240-010PMSRP = 15527.25	24X1	1	016

Flange Bolt Kits

Bolt Kit Selection Guide

Order Gaskets & Bolt Kits Separately

Kit Contains All Bolts, Nuts, & Flat Washers for Specified Flange Size

For Connecting Two (2) Mating Spears^® Flanges

Pre-coated, Anti-seize Lubricated Bolts

Available in Zinc Coated Steel, Type 304 Stainless Steel or Type 316 Stainless Steel

Flange Size	Bolts¹ Per Kit	Diameter (in.-TPI)	Length (in.)	Hardware Kit Part Number
Flange Size	Bolts¹ Per Kit	Diameter (in.-TPI)	Length (in.)	Zinc	316 SS	304 SS
1/2	4	1/2-13	2	HK-005	HK1-005	HK2-005
3/4 & 1	4	1/2-13	2-1/4	HK-010	HK1-010	HK2-010
1-1/4 & 1-1/2	4	1/2-13	2-1/2	HK-015	HK1-015	HK2-015
2	4	5/8-11	3	HK-020	HK1-020	HK2-020
2-1/2	4	5/8-11	3-1/4	HK-025	HK1-025	HK2-025
3	4	5/8-11	3-1/2	HK-030	HK1-030	HK2-030
4	8	5/8-11	3-1/2	HK-040	HK1-040	HK2-040
5 & 6	8	3/4-10	4	HK-060	HK1-060	HK2-060
8	8	3/4-10	4-1/2	HK-080	HK1-080	HK2-080
10 & 12	12	7/8-9	6	HK-120	HK1-120	HK2-120
1 - Each Bolt includes Nut & two (2) Flat Washers

Flange Bolt Hardware Kits - Zinc Plated Steel
For Connection of 2-Spears^� Flanges Includes - Bolts, Nuts & Flat Washers

HK-005MSRP = 20.77

1/2

017

Page 35

Suitable for Oil-Free air handling to 25 psi, not for distribution of compressed air or gas

Spears^® Manufacturing Company

See Spears^® On-line Catalog @ www.spearsmfg.com for Pricing

Schedule 80 CPVC Product
Flange Bolt Kits & Flange Gaskets - Full-Faced

Print this Book

Flange Bolt Kits

Part Number

Size

Std Pk

Mstr
Ctn

Prod
Code

Flange Bolt Hardware Kits - Zinc Plated Steel (continued)
For Connection of 2-Spears^� Flanges Includes - Bolts, Nuts & Flat Washers

HK-010MSRP = 25.91	3/4 & 1	1	10	017
HK-015MSRP = 38.98	1-1/4 & 1-1/2	1	10	017
HK-020MSRP = 52.18	2	1	10	017
HK-025MSRP = 62.54	2-1/2	1	10	017
HK-030MSRP = 71.99	3	1	10	017
HK-040MSRP = 149.15	4	1	5	017
HK-060MSRP = 165.83	5 & 6	1	5	017
HK-080MSRP = 194.36	8	1	0	017
HK-120MSRP = 262.97	10 & 12	1	0	017

Flange Bolt Hardware Kits - Type 316 Stainless Steel
For Connection of 2-Spears^� Flanges Includes - Bolts, Nuts & Flat Washers

HK1-005MSRP = 62.27	1/2	1	10	017
HK1-010MSRP = 89.65	3/4 & 1	1	10	017
HK1-015MSRP = 98.78	1-1/4 & 1-1/2	1	10	017
HK1-020MSRP = 118.80	2	1	10	017
HK1-025MSRP = 127.34	2-1/2	1	10	017
HK1-030MSRP = 168.02	3	1	10	017
HK1-040MSRP = 336.94	4	1	5	017
HK1-060MSRP = 439.49	5 & 6	1	5	017
HK1-080MSRP = 551.43	8	1	0	017
HK1-120MSRP = 1121.89	10 & 12	1	0	017

Flange Bolt Hardware Kits - Type 304 Stainless Steel
For Connection of 2-Spears^� Flanges Includes - Bolts, Nuts, & Flat Washers

HK2-005MSRP = 54.46	1/2	1	10	017
HK2-010MSRP = 77.69	3/4 & 1	1	10	017
HK2-015MSRP = 91.51	1-1/4 & 1-1/2	1	10	017
HK2-020MSRP = 107.64	2	1	10	017
HK2-025MSRP = 114.17	2-1/2	1	10	017
HK2-030MSRP = 141.75	3	1	10	017
HK2-040MSRP = 283.49	4	1	5	017
HK2-060MSRP = 298.81	5 & 6	1	5	017
HK2-080MSRP = 392.88	8	1	0	017
HK2-120MSRP = 696.36	10 & 12	1	0	017

Flange Gaskets - Full-Faced

Gasket Selection Guide

Flange Size	Bolt Holes	Gasket Part Number
Flange Size	Bolt Holes	Buna-N	EPDM	FKM
1/2	4	GK1-005	GK2-005	GK3-005
3/4	4	GK1-007	GK2-007	GK3-007
1	4	GK1-010	GK2-010	GK3-010
1-1/4	4	GK1-012	GK2-012	GK3-012
1-1/2	4	GK1-015	GK2-015	GK3-015
2	4	GK1-020	GK2-020	GK3-020
2-1/2	4	GK1-025	GK2-025	GK3-025
3	4	GK1-030	GK2-030	GK3-030
4	8	GK1-040	GK2-040	GK3-040
5	8	GK1-050	GK2-050	GK3-050
6	8	GK1-060	GK2-060	GK3-060
8	8	GK1-080	GK2-080	GK3-080
10	12	GK1-100	GK2-100	GK3-100
12	12	GK1-120	GK2-120	GK3-120

Order Gaskets & Bolt Kits Separately

1/8" Full-Face design with ANSI Class 150 Bolt Patterns
Pressure rated to 150 psi @ 73°F
Available in Buna-N, EPDM, or FKM

Flange Gaskets - Full-Faced Buna-N

Part Number	Size	Std Pk	Mstr Ctn	Prod Code
GK1-005MSRP = 6.67	1/2	1	25	017
GK1-007MSRP = 7.62	3/4	1	25	017
GK1-010MSRP = 8.20	1	1	25	017
GK1-012MSRP = 9.04	1-1/4	1	25	017
GK1-015MSRP = 9.36	1-1/2	1	25	017
GK1-020MSRP = 12.94	2	1	25	017
GK1-025MSRP = 16.91	2-1/2	1	25	017
GK1-030MSRP = 20.45	3	1	25	017
GK1-040MSRP = 31.37	4	1	25	017
GK1-050MSRP = 33.23	5	1	25	017
GK1-060MSRP = 33.78	6	1	25	017
GK1-080MSRP = 44.20	8	1	25	017
GK1-100MSRP = 66.15	10	1	25	017
GK1-120MSRP = 98.99	12	1	25	017
GK1-140MSRP = 137.13	14	1	25	017
GK1-160MSRP = 220.53	16	1	25	017

Made in the U.S.A.

Suitable for Oil-Free air handling to 25 psi, not for distribution of compressed air or gas

See Spears^® On-line Catalog @ www.spearsmfg.com for Pricing

Page 36

Schedule 80 CPVC Product
Flange Gaskets - Full-Faced & CPVC Flange Cut-in Kit

Print this Book

Flange Gaskets - Full-Faced

Flange Gaskets - Full-Faced Buna-N (continued)

Part Number	Size	Std Pk	Mstr Ctn	Prod Code
GK1-180MSRP = 325.65	18	1	25	017
GK1-240MSRP = 431.76	24	1	25	017

Flange Gaskets - Full-Faced EPDM

Part Number	Size	Std Pk	Mstr Ctn	Prod Code
GK2-005MSRP = 8.84	1/2	1	25	017
GK2-007MSRP = 9.40	3/4	1	25	017
GK2-010MSRP = 9.82	1	1	25	017
GK2-012MSRP = 10.32	1-1/4	1	25	017
GK2-015MSRP = 11.07	1-1/2	1	25	017
GK2-020MSRP = 14.12	2	1	25	017
GK2-025MSRP = 18.18	2-1/2	1	25	017
GK2-030MSRP = 22.63	3	1	25	017
GK2-040MSRP = 33.36	4	1	25	017
GK2-050MSRP = 44.93	5	1	25	017
GK2-060MSRP = 45.57	6	1	25	017
GK2-080MSRP = 67.39	8	1	25	017
GK2-100MSRP = 73.86	10	1	25	017
GK2-120MSRP = 102.43	12	1	25	017
GK2-140MSRP = 171.77	14	1	25	017
GK2-160MSRP = 232.44	16	1	25	017
GK2-180MSRP = 350.43	18	1	25	017
GK2-200MSRP = 408.29	20	1	25	017
GK2-240MSRP = 452.12	24	1	25	017

Flange Gaskets - Full-Faced FKM

Part Number	Size	Std Pk	Mstr Ctn	Prod Code
GK3-005MSRP = 31.55	1/2	1	25	017
GK3-007MSRP = 37.44	3/4	1	25	017
GK3-010MSRP = 47.16	1	1	25	017
GK3-012MSRP = 55.91	1-1/4	1	5	017
GK3-015MSRP = 76.18	1-1/2	1	25	017
GK3-020MSRP = 102.18	2	1	25	017
GK3-025MSRP = 160.77	2-1/2	1	25	017
GK3-030MSRP = 172.38	3	1	25	017
GK3-040MSRP = 231.31	4	1	25	017
GK3-050MSRP = 275.08	5	1	25	017
GK3-060MSRP = 337.20	6	1	25	017
GK3-080MSRP = 535.41	8	1	25	017
GK3-100MSRP = 712.18	10	1	25	017
GK3-120MSRP = 1003.41	12	1	25	017
GK3-140MSRP = 1129.05	14	1	25	017
GK3-160MSRP = 1474.11	16	1	25	017
GK3-180MSRP = 1599.15	18	1	25	017
GK3-240MSRP = 2348.33	24	1	10	017

CPVC Flange Cut-in Kit

When planned system changes are needed, system downtime can be a major concern. Spears^® Flange Cut-in Kit minimizes downtime for actual cut-in to allow new connection in just minutes. Kit provides all necessary components to create a flanged joint for connection to system alterations in just minutes. Special Flange Hub can be cemented to piping and allowed to cure before shutting down and cutting into system. This allows immediate joining to mating flange (included) that can also be pre-assembled to desired alteration piping.

Kit includes special Split Flange Socket Hub, O-ring Sealed Hub Body, Stainless Steel Clamp, Split Ring, Full-Faced EPDM or FKM Gasket, Mating Flange Hub & Ring, and complete set of Stainless Steel Bolts, Flat Washers and anti-seize Brass Nuts to make the final joint. Available for IPS Pipe Sizes 1-1/2" - 12".

Pressure Rated to 150 psi @ 73°F (22°C)
Maximum Service Temperature
PVC = 140°F (60°C)
CPVC = 200°F (93°C)
Temperature/Pressure De-ratings Apply

Flange Cut-in Kit

Size	EPDM Gasket	FKM Gasket	Std Pk	Mstr Pk	Prod Code
1-1/2	FCKE-015CMSRP = 1284.36	FCKV-015CMSRP = 1366.11	1	4	017
2	FCKE-020CMSRP = 1434.55	FCKV-020CMSRP = 1513.67	1	4	017
2-1/2	FCKE-025CMSRP = 1528.62	FCKV-025CMSRP = 1654.75	1	0	017
3	FCKE-030CMSRP = 1665.25	FCKV-030CMSRP = 1729.26	1	0	017
4	FCKE-040CMSRP = 2547.54	FCKV-040CMSRP = 2646.52	1	0	017
6	FCKE-060CMSRP = 4125.81	FCKV-060CMSRP = 4699.94	1	0	017
8	FCKE-080CMSRP = 5235.80	FCKV-080CMSRP = 5964.92	1	0	017
10	FCKE-100CMSRP = 8479.92	FCKV-100CMSRP = 8762.18	1	0	017
12	FCKE-120CMSRP = 10090.36	FCKV-120CMSRP = 10532.99	1	0	017

Page 37

Suitable for Oil-Free air handling to 25 psi, not for distribution of compressed air or gas

Spears^® Manufacturing Company

See Spears^® On-line Catalog @ www.spearsmfg.com for Pricing

Spears Super Sourcebook prints best when the margins are set to our specifications and the headers and footers are turned off.

The Spears Product Price Schedules will print on standard 8.5 x 11 paper with the following changes to your browsers page setup.

For Microsoft Internet Explorer Version 8 & 9:

Select File/Page Setup
Set Orientation to Portrait.
Check �Print Background Colors and Images.�
Set the Margins as follows:

Left 0.875
Right 0.875
Top 0.375
Bottom 0.375

Select �-Empty-� in all the Header and Footer dropdown boxes.
Click OK.
